Owners Manual For All
Wood Heaters
COVERS MODELS:
HOTHAM
THREDBO
THREDBO INSERT
PERISHER
Tested and approved to Australian Standards AS/NZS 2918:2018
and AS/NZS 4013/4012:2014.
Prior to installation check with your state and local authorities
regarding any specific regulations that may apply.
Please keep these instructions for future reference.
Burn hardwood only.
Barbeques Galore proudly
supports the activities of
Landcare Australia through its
membership of the AHHA.
Congratulations on your purchase of a quality Austwood wood heater. This product is designed according to strict
environmental, quality and safety standards and should give you years of trouble free home heating.
Read these instructions carefully to get the most out of your heater and to ensure safe and satisfactory heater
performance. In particular, we would like to draw your attention to these warnings.
Use only dry, well seasoned hardwood.
Do not use coal or briquettes.
Do not burn garbage in the firebox as garbage
can cause a dangerous soot build up and
increase the amount of smoke your heater
produces.
Do not burn chemically treated timber as the
poisonous gases given off could damage your
stove.
CAUTION: THE USE OF SOME TYPES OF
PRESERVATIVE-TREATED WOOD AS FUEL
CAN BE HAZARDOUS.
Do not place any types of builders board eg
fibro, cement sheeting (or any other materials
not specified and tested by the manufacturer)
inside the firebox.
The exterior surfaces of the heater will become
hot during operation. For protection of
children, the elderly or infirm, provide a
firescreen to prevent contact with the
appliance in operation.
To protect against injury from burns, use
caution when operating the appliance. In
particular, when loading the firebox, provide
adequate protection for your hands.
CAUTION: THIS APPLIANCE SHOULD BE
MAINTAINED AND OPERATED AT ALL TIMES
I N A C C O R D A N C E W I T H T H E S E
INSTRUCTIONS.
CAUTION: THIS APPLIANCE SHOULD NOT
BE OPERATED WITH A CRACKED GLASS.
Do not throw logs into the firebox. Always
place logs carefully.
Load logs with ends pointing to the front of the
heater. This will help prevent logs rolling
forward.
Do not overfire as this could damage your
firebox.
The appliance or flue system should not be
modified in any way without the written
approval of the manufacturer.
Do not place clothing or other combustible
materials on top of the heater.
Do not store flammable liquids near the
heater.
Do not store fuel close to the stove.
Whilst every care has been taken in formulating these instructions, no responsibility whatsoever will attach to and/or
claim lie against, the manufacturer and/or the distributor of the heater as a result of any failure to follow the whole or
any part of the instructions and/or as a result of incorrect information herein and/or any omission here from.
Your heater comes almost completely assembled. There is only a simple matter of placing the bricks and brick
retainer, positioning the baffle plate, and the heater is ready to be installed.
FIREBRICK PLACEMENT
There are three sizes of firebox in the Austwood
range, and each has its own arrangement of
firebricks. Refer to the diagrams below for your
model of heater. The bricks are placed with their
longest edge upright.
There will be gaps in between the firebricks. Allow
the ash to settle in between - there is no need to
remove the bricks when cleaning the firebox.
Brick Sizes
A - 173 x 74 B - 173 x 200
C - 119 x 200 D - 119 x 74
BRICK RETAINER
To hold the firebricks in place, you should position
the brick retainer bracket over the firebricks as
shown below.
C
C
C
C
C
C
C
C
C
B
B
C
C
C
C
C
B
B
B
B
B
B
A
D
C
C
C
C
C
B
B
B
B
B
B
A
D
C
D
A
BAFFLE PLATE
The baffle plate for your Austwood heater consists
of a steel frame and a Skamolex baffle. To place
the baffle into the heater, first place the Skamolex
baffle into the steel frame then position into the
firebox.
You may need to angle the baffle up on one side
to get it through the door. You should then lift the
baffle over one bracket, push it up to the top of the
firebox, and then lift it over the other bracket.
Ensure the baffle plate is pushed all the way to the
back of the heater.
1
2
