Read this user manual and in
particular the safety notes,
before using the product.
Keep the user manual for future
reference and include it when passing the
product on to third parties.
Esprinet S.p.A. will not in any way be
held responsible for injury or damage
caused to persons or property arising
from misuse of the product.
Safety notes
Only connect the product in indoor areas
to a properly installed 100–240 V AC
socket.
Only connect the product to an easily
accessible socket so that you can quickly
disconnect it from the power supply in
the event of a problem.
Do not use the product if it is damaged.
Never touch the product with wet or
damp hands.
Only use the product indoors. Do not use
in damp rooms or in the rain.
Never insert metallic objects such as
keys or paper clips into the openings of
the product.
To prevent malfunction or damage to the
product, avoid accidental falls, do not
crush, puncture or exercise a high level of
pressure on the product.
Keep away from humidity, water or other
liquids. If the product comes into contact
with water, moisture or other liquids, do
not use it to avoid any electrical shock
or damage.
Do not store or expose your product
to any source of heat, direct sunlight,
radiators, stoves or other heat sources
such as the dashboard of your car in the
summer.
Never operate the product unsupervised.
During operation, the housing may
become hot.
Do not cover the product during use.
Never use the product when moving from
a cold to a warm environment.
Condensation may occur and, in some
cases, damage the product. Allow the
product to reach room temperature
before connecting and using it again.
Temperature of use: 0–40 °C.
Do not try to modify, repair or
disassemble the product.
Do not use a damaged product. Do
not under any circumstances use
aggressive cleaning agents, alcohol or
other chemical solutions for cleaning as
they can damage the housing or even
impair the functionality of the product.
Disconnect all connected cables before
you start cleaning. Do not immerse
the product in water or other liquids.
ere are no serviceable parts inside
the product. Never open/disassemble it.
Keep the product out of reach of children.
Never allow children or persons with
disabilities to use electrical products
without supervision. Make sure that
children do not play with the plastic
wrapping. they may swallow it when
playing and suffocate.
Use
1. Before charging your device, make
sure its technical characteristics (voltage,
output and amperage) are compatible
with the charger.
2. Connect your device’s USB cable to
your device.
3. Connect your device’s USB cable to
the USB port of the charger.
4. Plug the charger into a wall outlet
(100–240V AC). Charging of your device
will be started.
5. Disconnect the charger from the wall
socket and your device after use.
Cleaning
Disconnect all cables before cleaning.
If necessary, clean the charger with a
damp cloth and let it dry completely
before use.
Use a clean brush with soft, long bristles
to remove dust on the connectors.
Do not use any solvents, corrosive or
gaseous cleaning agents.
Make sure no water or other liquids
penetrate the housing.
Storage
Store the charger in a clean, dry area.
Keep it away from direct sunlight.
Disposal of the product
(Applicable in countries with
separate collection systems of
recyclable materials)
Old products may not be disposed of in
the household waste! Should the product
no longer be capable of being used
at some point in time, dispose of it in
accordance with the regulations in force
in your country. is ensures that old
products are recycled in a professional
manner and also rules out negative
consequences for the environment.
For this reason, electrical equipment is
marked with the symbol shown here.
Technical specifications
Input: 110-240V AC, 50/60Hz, 0,3 A
Output (USB-C PD): DC 5V, 3 A, 15,0 W,
2% / DC 9V, 2,22 A, 20,0 W, 2% /
DC 12V, 1,67 A, 20,0 W, 2%
Average active efficiency: 83,13 %, 2%
Efficiency at low load (10 %): 81,28 %, 2%
No-load power consumption: 0,078W, 2%
is product complies with
RoHS 2011/65/EU - 2015/863/
EU. e product carries the CE
mark and complies with safety standards
established by the European Union.
Double insulation
Only for indoor use
Celly® is a trademark owned by Esprinet
S.p.A.
All brands are registered trademarks of
their respective owners.
Esprinet S.p.A., via Energy Park
20, 20871 Vimercate (MB) -
Italy
Made in China.
User manual
WALL CHARGER
Model: TC1USBC20WWH
Rev04 - 30.03.2023
EN
