HIGH PERFORMANCE ATX POWER SUPPLY
AX850
AX1000
EMAIL: support@corsair.com
FACEBOOK: facebook.com/corsair
BLOG: blog.corsair.com
FORUM: forum.corsair.com
TWITTER: twitter.com/corsair
USA and CANADA: | INTERNATIONAL: | FAX: (510) 657-8747 (888) 222-4346 (510) 657-8748
corsair.com
47100 BAYSIDE PARKWAY • FREMONT • CALIFORNIA • 94538 • USA
© 2010–2018 CORS AIR COMPONENTS, INC. All right s reserved.
CORSAIR and the sails logo a re registered trademarks in the United States
and/or other countries. All other trademarks are the property of their respective
owners. Product may va ry slightly from those pictured. 49-001614 AA
MANUAL • MANUEL • MANUALE • MANUELLE • MANUAL DE
РУКОВОДСТВО • MANUAL • MANUELL • • 用户手册 取扱説明書

English 1
Français 11
Deutsch 21
Italiano 31
Español 41
Русский 51
Português 61
Svenska71
中文 81
日本の 91

1 2
AX SERIES
™
AX SERIES
™
Product Specifications
AX ..........................
AX ............................
Installation ....................
ImportantSafety
Information ...................
SafetyandAgency
Approvals ....................
Congratulations on the purchase of your new CORSAIR
AX Series High Performance ATX power supply.
CORSAIR AX Series power supplies are built with the highest quality
components to deliver 80 PLUS Titanium ecient power to your
PC, reducing power costs and excess heat. Using only Japanese
105°C capacitors, users can be depend on an AX PSUs’ long life and
reliability, backed by a ten year warranty. Zero RPM Mode means
an AX Series PSU is virtually silent at low and medium loads, and
even at maximum power, a low noise fan ensures quiet operation.
Fully modular cables make PC builds and upgrades easy, as you only
need to install the cables your system requires. Quiet, ecient and
dependable, an AX PSU has everything you need to power your PC
for years to come.
Safety and protection
• Over-voltage protection (OVP)
Over-voltage protection for the 12V, 5V and 3.3V DC outputs
is required to comply with the ATX specication. OVP shuts
down the PSU in the event that the DC outputs exceed a set
level, determined by the PSU manufacturer. The minimum
voltage levels required for compliance are 13.4V for the
+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.
• Over-current protection (OCP)
The AX Series features OCP on the 3.3V, 5V and 12V rails.
OCP ensures that the output of the DC voltage rails remains
within safe operating limits.
• Over-temperature protection (OTP)
OTP ensures that the PSU will shut down when the internal
temperature reaches a set point. This is usually as a result
of internal current overloading or a fan failure.
• Short-circuit protection (SCP)
A short-circuit is dened as any output impedance of less than
0.1 ohms. Amongst other things, SCP ensures that the PSU shuts
down should the 3.3V, 5V and 12V rails short to any other rail, or to
ground. It also ensures that no damage should occur to the unit, or
your PC’s components in the event of a short.
