How to Install

1. Decide the preferred hanging height and

choose the correct length of rods chainand

needed.

2.Feed the wires through the rods and screw

the rods onto the top of the xture. Attach the

quick link on end of the chain to the top ofone

the rod. Repeat for the other rod using

another chain.

3. Attach the mounting strap onto the outlet box.

4. Raise the fixture up to the ceiling and do the

wire connections. Put the canopy up against

the ceiling completely tighten thethen

screws on the side to secure the canopy.

5. Install the bulb into the socket.

6. Dress the glass as illustrated.

Glass Sets

1.72 pcs Clear glass 2 3/4x7 3/4”

Crystorama.com

You will need 14 Candelabra Base Bulb

40 Watts Recommended 60 Watts Max.

USE LED BULBS FOR EXTENDED USE

( This fixture is Dry rated)

Ø16 [

5

8

"]

400 [15

3

4

"]

20 [

3

4

"]

353 [137

8"]

1310 [51

5

8

"]

346 [135

8"]

72PCS

3000[118"]

Dress the glass from inner ring

Clear

ADD-317--CLAG

Rods 2*12"
