ASSEMBLYINSTRUCTIONMODEL#131-MK

CRYST

RAMA

WARNING:

ElectricalDanger

TurnPoweroff

WARNING:ThisproductcanexposeyoutoLead

whichisknowntothestateofCaliforniatocausecancer

and/orbirthdefectsorreproductiveharm.Formore

informationgotowww.P65Warnings.ca.gov

LIGHTINGTHEWAYFORSIXTYYEARS

installedbyalicensedelectrician

inaccordancewiththeNational

Allelectricalcomponentsmustbe

ElectricCodeandtheappropriate

localelectricalcodes.

Youwillneed1-MediumBaseBulb

40WattsRecommended60WattsMax.

USELEDBULBSFOREXTENDEDUSE

ThisfixtureisDamprated

A-14sets

B-14sets

A-10sets

B-10sets

A-5sets

B-5sets

C-1set

Bottom

basket

Socket

Loop

5-7/8’’

1-1/8’’

13-3/4’’

7-1/4’’

13’’

A=

30mmx29sets

B=

76mmx29sets

C=

(30mmBallwithchain)x1set

Metalring

Howtoinstall

Forceiling:

Forhanging:

7.HangglassdropCatthebottomofthebottombasket.

8.Installthebulb(notincluded)intothesocket.

1.Determinethepreferredhangingheightand

adjusttothechainrequired.

2.Openonelinkofchainconnectittofixtureloop

andclosethelink.Opentheotheronelinkofchain

connectittoloopofcanopyandclosethelink.

3.Threadthemountingscrewsintothematching

holesofthemountingbar,andtightenwiththe

smallhexnut.

4.Securethemountingbartotheoutletboxwith

theoutletboxscrews.

5.Raisecanopyallowingthemountingscrewsto

protrudethroughtheholesinthecanopy,and

securewiththeballnut.

1.Loosethehexnutofcanopyanddisassemblecanopy.

2.Removethelooponthetopofthefixture.

3.Slipthecanopy,themetalwasherandlockwasherover

thenipple,thensecurewiththehexnut.

4Threadthemountingscrewsintothematching

holesofthemountingbar,andtightenwiththe

smallhexnut.

.

5Securethemountingbartotheoutletboxwith

theoutletboxscrews.

.

6.Raisecanopyallowingthemountingscrewsto

protrudethroughtheholesinthecanopy,and

securewiththeballnut.

9.HangglassdropCatthebottomofthebottombasket.

7.Installthebulb(notincluded)intothesocket.

6.Hangcrystalstothemetalringandbottombasket,

alternatingbetweenglassdropAandB.

8.Hangcrystalstothemetalringandbottombasket,

alternatingbetweenglassdropAandB.

Hangcrystalsontheringsalternating

betweencrystalsAandB
