Analog High Definition 2MP Cameras

DWC-D4783WTIR

Dimensions (unit : mm

[

inch

]

)

866.446.3595

Rev Date: 6/15Copyright © Digital Watchdog 2015. All rights reserved. Specifications and pricing are subject to change without notice.

sales@dwcc.tvdigital-watchdog.com

Summary

Groundbreaking STAR-LIGHT AHD™ High Definition Cameras use existing

coaxial cables to transmit crystal-clear detailed 1080p images. The

cameras oer 2.1MP resolution along with powerful features such as P-Iris

Lens, Double Shutter Wide Dynamic Range (WDR) and True Day/Night with

Mechanical IR Cut Filter. The STAR-LIGHT AHD cameras are engineered to

work with VMAX AHD DVRs, oering an easy upgrade from analog to high

definition surveillance using existing infrastructure for a cost-eective, high

resolution surveillance solution.

Features

•

Analog High Definition (AHD) HD over Coax Technology

•

STAR-LIGHT™ Super Low Light Technology

•

Panasonic 1/3" CMOS Sensor

•

1080p Resolution at 30fps

•

Wide Dynamic Range (WDR)

•

Auto Focus P-Iris Lens from 2.8

~

12mm

•

Smart IR™ with Intelligent Camera Sync. 70ft Range

•

Smart DNR™ 3D Digital Noise Reduction

•

Highlight Masking Exposure (HME)

•

True Day/Night with Mechanical IR Cut Filter

•

Auto Sensing 24VAC/12VDC with Line Lock

•

Secondary Video-BNC Output

•

Easy Icon Driven OSD Menu with Built-in Joystick

•

Programmable Privacy Zones

•

Auto Gain Control (AGC)

•

Backlight Compensation (BLC)

•

Dynamic Range Compressor (DRC) Reveals Low Light Detail

•

Auto White Balance (AWB)

•

UTP Built-In

•

RS-485 Built-in

C-D4783WTIR


Image SensorPanasonic 1/3" CMOS

Active Pixels1944 (H) x 1092 (V)

Scanning SystemProgressive Scan

Frequency60Hz / 50Hz

Signal Technology2.0 Megapixel AHD

SynchronizationInternal

Resolution1920x1080 (1080p)

Minimum Scene Illumination

F1.4 (30IRE): 0.35Lux [Color]

F1.4 (30IRE): 0 Lux [B&W]

S/N Ratio55dB

Video OutputAHD 1080p30fps / 720p60fps / 720p30fps

Alarm Output1 Alarm Output

LENS

Focal Length2.8

~

12mm

Lens TypeAuto Focus P-Iris

IR Distance70ft

OPERATIONAL

Shutter Speed1/30(25) – 1/30,000

BacklightO / On

STAR-LIGHT (Sense-up)O, x2 – x32

Wide Dynamic Range (WDR)O / On

Digital Noise ReductionO, Low, Middle, High

White BalanceAuto / Auto-Ex / Preset / Manual

Day and NightDay / Night / Auto

Mirror / FlipYes

Auto Gain ControlMax 60dB

Motion DetectionYes

Privacy Zones16 Privacy Zones

Sharpness0

~

10

Gamma0.45

~

0.75

RS485 / UTP Built-inPELCO D / PELCO C

Digital Zoomx1.0

~

x16.0

ENVIRONMENTAL

Operating Temperature-20°C

~

50°C (-4°F

~

122°F)

Operating HumidityLess than 90% (Non-Condensing)

Other CertificationsFCC, CE, ROHS

ELECTRICAL

Power RequirementsDC12V / AC24V Dual Voltage

Power Consumption

DC12V: 3.43W, 286mA, LED On: 6.45W, 537mA

AC24V: 3.3W, 137mA, LED On: 5.95W, 248mA

MECHANICAL

MaterialPlastic

Dimensions108 x 96.8 mm (4.25 x 3.81 inch)

Weight240 g (0.529 lbs)

Specifications

*Specifications subject to change without notice.

Ø108.0mm

[4.25"]

96.8mm

[3.81"]

56.3mm

[2.22"]

40.5mm

[1.59"]
