Foster spa
via M.S. Ottone, 18/20
42041 Brescello (RE) - Italy
tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450
fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166
e-mail: service@fosterspa.com
www.fosterspa.com
INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
Stainless steel sinks
cod. 9606801
Istructions for the installation,
use and maintenance of
kitchen stainless steel sinks
Sinks’ material: austenitic stainless steel AISI 304 - 18/10
UNI EN 13310:2004
(kitchen sinks for domestic use, functional features and tests’ methods)
INSTALLATION
Standard and at (3 mm bended) edge
Before making any cut-out on the worktop, we suggest to verify and lay the sink on the
worktop itself and/or on the cabinets in order to verify that the external dimensions of the
bowls are compatible with the cabinets themselves, in order to avoid making cut-outs for
sinks that cannot be installed.
We also recommend to verify the possibility to install taps and other accessories, by
checking the place they need and the place that remains. Also verify the possibility to
accede to the water main tap under the sink, and that the positioning of the siphon is
feasible. To install the sink, one must make a cut-out on the worktop according to the
template included in the packing.
Once the cut-out is made, one must position the gasket around the perimeter of the
hole. Before installing the sink, please position the waste-fitting and overflow pipe (when
present); when available, also the command of the autiomatic waste-fitting must be
installed at this stage. Make
sure that the external edge
of the sink is positioned
upon the gasket, so as to
create a barrier preventing
the infiltration of water
and dirt between sink and
worktop.
'PTUFS
After having positioned the sink on the worktop, fix it by tightening the screws of
the brackets which are provided (the screws must be tightened just enough to have
the brackets clamp down on the worktop).
Afterwards, remove the excess gasket with a
cutter. The taps can be installed before or after
the positioning of the sink.
After having installed the sink, connect the
waste-fitting with the siphon. Check the water-
tightness by closing the basket of the waste-
fitting, open the tap and wait until the water
level reaches the overflow; shut the tap, and
wait several minutes, verifying that the water
does not drain away. Empty the sink.
Flush-mount edge
For a correct installation of the flush-mount sinks, please follow strictly the technical
sheet (template) provided with the sink; only qualified personnel should make the cut-
out, and a computer-operated machine is necessary. It is advisable to accurately clean
the seat for the cut-out, and to insert the gasket which is provided, between the sink and
the worktop, so as to avoid possible water infiltration into the worktop or the cabinets.
The work must be carried out by experienced personnel.
Do not use electric screwdrivers to tighten the brackets.
The tightening torque must not exceed 60 N/cm.
It is advisable to install the flush-mount sinks on hydro
repellent materials, in order to avoid eventual deformations
of the material itself.
