Canopy
1ea
Mounting
Screws 2ea Top loop 1ea
Chain 6ft Threaded ring 1ea Wire connectors 2ea
Chain connector 2ea Canopy loop 1ea Nipple 1ea
Mounting Strap 1ea Hex Nut 1ea Finial 1ea
Part Needed Quantity
Part Needed Quantity
Reason why ( missing, scratched, broken glass, bent, bad nish)
Comments
F A IIXTURE SSEMBLY NSTRUCTIONS
For Customer Service, contact the place of purchase to arrange for replacement parts.
NOTE: INSTALL THE GLASS ASSEMBLY
AFTER THE FIXTURE IS HUNG.
1. Feed the xture wires through the Top loop (J)
and pull the wires until taut.
2.Then screw the Top Loop (J) to the top of Frame
(K) until tight.
8106-D5 CDB
Read and review installation instruction sheet before
assembling the xture.
Fig 1
Notice: Please review the parts listing and check for all parts before assembling the xture. If any parts are
missing or damaged, please note onthis sheet and contact the place of purchase to arrange for
replacement parts.
PARTS LIST Company Name:_______________________Co. Account #:_____________
to be lled out by retailer
PARTS & ASSEMBLY SHEET
This xture assembled PO:__________ Date: ________
Fixture Name: Torbellino 8106-D5 CDB
K
CHAIN
J
H
For Customer Service, contact the place of purchase to arrange for replacement parts.
8. By measuring determine correct number of links
needed for proper hanging height. Use a pair of
pliers to open one link of the Chain (C2) then
remove the excess Chain (C2) and discard it.
9. Use one chain connector(E2) to attach one end
of the chain to the Top loop (D2) and close the
chain connector.
10. Feed the xture wires through the Chain (every
three links) and pull the wires until taut.
11. Slip Canopy loop collar (B2) over the chain,
then do the same with the canopy (F2).
12. When ready to complete the installation Use the
other chain connector and attach the other end of
the chain to the canopy loop (A2) and close the
chain connector.
13. Make sure the weight of the chandelier is
supported by the chain-not the electrical wire.
* You may now install the xture.
Fig 3
3. Unscrew two of the Deco screws (L) from the
Frame (K) and save.
4. Two arms are already attached to the Frame.
Gently spread the arms until evenly spaced.
5. Align the hole in lower side of Frame arm (K) with
hole Frame(K). Secure in place with the Deco
screw (L).
6. Repeat with remaining arms and Deco screws.
* NOTE: The Finial can be scratched or broken if
the full weight of the xture is placed on it. To avoid
damage attach Finial after hanging the xture.
7. Attach Finial (N) to the base of xture Frame (K)
by threading the Finia l(N) onto the threaded rod
(M) until tight.
Fig 2
PARTS & ASSEMBLY SHEET
Fixture Name: Torbellino 8106-D5 CDB
Note: Complete these remaining steps after the
xture is hung.
14. Place the Glass Shade (P) over the Threaded
Socket (O),place the Socket washer (Q) over the
threaded socket (O) then secure the Glass Shade
(P) by threading by the Socket Ring (R) until tight.
15. Install the light bulbs in accordance with the
xture's specications.
(DO NOT EXCEED THE MAXIMUM WATTAGE RATING)
Fig 4
B2
A2
C2
E2
D2
E2
O
Q
P
K
M
N
L
CHAIN
J
O
Q
R
P
M
L
INSTALLATION INSTRUCTIONS
Fixture Name: Torbellino 8106-D5 CDB
For Chandelier Light Fixture
13. Raise Canopy (G) to the ceiling and secure in place by
tightening the Canopy loop collar(H) into the Canopy Loop(F)
14. Install the light bulbs and glass shade as per the xture
assembly sheet.
YOUR INSTALLATION IS NOW COMPLETE.
RETURN POWER TO THE JUNCTION BOX
AND TEST THE FIXTURE.
For Customer Service, contact the place of purchase to arrange for replacement parts.
7. Unscrew the Canopy loop collar (H) from the Canopy loop.
Take the canopy and pass over the Canopy loop. approximatly
one half of the canopy loop exterior threads should be exposed.
Adjust until desired height is reached. *the Canopy loop collar
should t snugly on the Canopy loop after the canopy is
installed. Remove Canopy and Canopy lock collar.
8. Assemble the xture and have an assistant or secure support
hold the weight of the xture while you complete the wiring
connections.
9.Thread the xture wires and ground wire of the assembled
xture through the canopy loop and nipple and into the outlet
box.
WARNING ! SHUT OFF POWER AT FUSE OR CIRCUIT BREAKER.
HANGING THE FIXTURE (Fig.1)
1. Carefully remove the new xture from the carton and the
yellow bag that holds all parts. Check that all parts are included
as shown in the illustration and parts list.
2. Shut o the power at the circuit breaker and remove old
xture from ceiling, including the old mounting strap.
3. Thread Nipple(C) into Canopy Loop (F) until snug.
4. Thread other end of the Nipple (C) with Canopy Loop
attached into Mounting Strap (D).
5. Place Lock Washer (B) over end of Nipple (C) protruding
through Mounting Strap (D) and thread Hex Nuts (A) onto Nipple
until tight.
6. Take this mounting strap assembly and mount to ceiling
junction box with junction box Screws (E). Tighten screw
securely with screw driver.
Fig. 1
CONNECTING THE WIRES (Fig 2)
10. Attach the power supply wires to the xture lead wires by
connecting BLACK to BLACK (or SMOOTH) and WHITE to
WHITE (or RIBBED).
11. Attach the GROUND wire(GREEN or COPPER) from the
Junction Box and the xture Ground wire to the green Ground
Screw on the Mounting Bracket (D) or connect both wires
together using the correct size of wire connectors.
NOTE: Twist the wires together in the same direction you twist
the wire connector onto the wires.
12. Tuck these wire connections neatly into the Junction Box.
Fig. 2
G
CHAIN
J
H
F
E
D
JUNCTION BOX
(CEILING)
A
C
B
