Description
Hartke’s HF44 Bass Fuzz Pedal features an
all-analog, FET design delivering the high-voltage
sound of a tube overdrive circuit. The Mid and
Tone controls allow you to dial in the harmonic
character while adding body and thickness to
your tone. The HF44 delivers the high-frequency
edge needed to drive all your aggressive riffs.
Features
• Compact, all-analog overdrive pedal for bass guitar
• FET circuitry provides high-gain, tube-like saturation
• Mid and Tone controls dial in harmonic
character and high-frequency edge
• Rugged, die cast design
For more information about the HF44 Bass Fuzz pedal
and the rest of our product line, visit hartke.com.

1. POWER In - Connect a 9V DC 300mA with
center negative
2. LEVEL Knob - Controls the amount of the
effected signal.
3. GAIN Knob - Adjusts the amount of
distortion and sustain.
4. MID Knob - Adjusts the mid frequency
response of the effected signal.
5. TONE Knob - Adjusts the high frequency
response of the effected signal. Turning
the knob clockwise brightens the sound.
6. INPUT - Connect the INPUT of the pedal
to your instrument output or some other
effects unit with a 1/4” mono phone plug
7. OUTPUT - Connect the OUTPUT of the
pedal to your guitar amplifier or the Input
of another effects unit.
8. On/Off Indicator - Lights when the effect is
enabled.
9. ON/OFF Switch - This footswitch is used to
turn effect on or off.
6
8
5
1
2 3
7
4
9
Controls

Installing the Battery
Install a standard 9-volt battery by removing the battery door and attaching the battery to the
terminal connector. Fit the battery into the compartment and reinstall the battery door.
Using a AC/DC Power Adapter
You can power the HF44 using a 9V power supply. Simply plug the power adapter into the DC
inlet and then, plug the power adapter into a standard AC power outlet.
Specifications
Power 9V Battery, AC Adaptor
Current Requirements 9mA at 9V
Connections Input, Output, DC Input
Input Impedance 1MΩ
Output Impedance 1OkΩ
Controls Depth, Speed, Blend
Dimensions LxWxD 4.8” x 3” x 1.9”
121mm x 77mm x 48mm
Weight 0.5lb / 230g
Hartke • 45 Gilpin Avenue,Hauppauge, New York 11788-8816 p.1-800-372-6766 ©2016, V1.1
