JBL CINEMA VISION

CVIW50

INSTALLATION MANUAL

INCLUDED

TM

R

One inwall

adaptor frame

One inwall

adaptor grille

Self-adhesive JBL logo

for placement on

metal mesh grille

Template/paint shield

(punch out at perforation).

Two speaker

attachment braces

8 small bolts

4

If it is necessary to remove the grille after installation, in order to avoid scratching the grille

or frame, you may unfold a paper clip, insert the straight end through one of the holes

in the grille, and gently pull up.

All features and specifications are subject to

change without notice.

Plate Size (W H)X

10” 28-1/8” (254mm 714mm)XX

Mounting Cutout Size

(W H)X

8-5/8” 26-13/16” (219mm 681mm)X X

Mounting depth

3-7/8” (98mm)

Weight with CVSAT50

or CVCEN50 attached

12 lbs (5.5 kg)

REMOVING THE GRILLE

You will need to purchase the CVRIF50 rough-in frame kit.

Detailed installation instructions are supplied with the rough-in kit

NEW CONSTRUCTION

SPECIFICATIONS

.

Declaration of Conformity

We, Harman Consumer International

2, route de Tours

72500 Chateau-du-Loir

France

declare in own responsibility that the products described in this

owner’s manual are in compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Gary Mardell

Harman Consumer International

Chateau-du-Loir, France 4/04

OWNER’S GUIDE

PRO SOUND

COMES HOME

PRODUCT LINE:

JBLCinema Vision

TM

TM

MODEL:

CVIW50

JBL Consumer Products

250 Crossways Park Drive, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91328

516.255.4JBL (4525) WWW.jbl.com

NOTE: For new-construction applications, be sure

to purchase the CVRIF50 rough-in frame kit.

C

2005 Harman International Indusrties, Incorporated

JBL is a registered trademark of Harman International

Industries, Incorporated.

Part No. 4006 - 000 - 05200.

A Harman International Company
