built-in cooker, 60 x 60 cm, Black
JH4306062
Included accessories
1 x combination grid, 1 x universal pan
Optional accessories
JZ11CB10E0 Baking tray, enamelled
JZ11CR10X0 Wire shelf
JZ11CU10E0 Multipurpose pan, enamelled
JZ11TI15X0 Cliprails
JZ1352X0 Pizza pan, enamelled
JZ1608BX0 Full ext rails, level independent
The Junker cooker in elegant black glass
design with LED display, 5 modes and
full-glass inner door with Soft Close.
• LED display: Modern and comfortable usage with pop-out knobs and LED
display.
• 5 modes: Flexible selection between 5 modes and therefore the right
solution for every meal.
• Full-glass inner door with Soft Close: Quiet, gentle closing of the easy to
clean jointless oven door.
• Child Lock: Quickly locking all functions by touching the button to prevent
interfering from little fingers
• Rapid heating: Up to 30% shorter preheating time with the same energy
consumption.
Technical Data
Gross weight: ....................................................................................... 38.2 kg
Built-in / Free-standing: .........................................................................Built-in
Integrated Cleaning system: ........................................................................No
Min. required niche size for installation (HxWxD): .. 600-604 x 560-568 x 550
mm
Dimensions: .....................................................................595 x 594 x 548 mm
Dimensions of the packed product (HxWxD): ................. 675 x 660 x 690 mm
Control Panel Material: ........................................................................... Glass
Door Material: ......................................................................................... Glass
Net weight: ........................................................................................... 36.2 kg
Usable volume of cavity: ............................................................................ 71 l
Cooking method: ... Full width grill, Hotair gentle, Hot Air, Conventional heat,
Hot air grilling
Number of interior lights: ................................................................................1
Interior Lights - cavity 1: .................................................................................1
Auszugssystem: ........................................................................... Nachrüstbar
Included accessories: .........................1 x combination grid, 1 x universal pan
Broil Element Wattages cavity 1: .........................................................2700 W
Convection Element Wattages cavity 1: ..............................................2200 W
Energy efficiency rating: ................................................................................ A
Energy consumption per cycle conventional - NEW (2010/30/EC): ........ 0.97
kWh/cycle
Energy consumption per cycle forced air convection - NEW (2010/30/EC): 0.81
kWh/cycle
Energy efficiency index (2010/30/EC): ................................................. 95.3 %
Connection rating: ............................................................................. 11200 W
Fuse protection: .................................................................................... 3*16 A
Voltage: ........................................................................................... 220-240 V
Frequency: ........................................................................................50; 60 Hz
Plug type: ................................................................. no plug, fixed connection
Energy input: ........................................................................................ Electric
Required cutout/niche size for installation (in): .............................................. x
Dimensions of the packed product: ...............................26.57 x 25.98 x 27.16
Net weight: ...................................................................................... 80.000 lbs
Gross weight: .................................................................................. 84.000 lbs
Net weight: ........................................................................................... 36.2 kg
1 /
built-in cooker, 60 x 60 cm, Black
JH4306062
The Junker cooker in elegant black glass
design with LED display, 5 modes and
full-glass inner door with Soft Close.
Type of oven / heating system:
- Built-in cooker with 5 heating methods: 3D Hot air plus, Top/bottom heat,
Hot air grilling, Full width grill, Hotair gentle, Halogen interior lighting
- Temperature range 50 °C - 275 °C
- Cavity volume: 71 l
Hook-in racks / rails
- Number of shelf levels: 5 PC
- Telescopic shelf rails as optional accessory
Design:
- Rotary Control, Retractable controls
- Cavity inner surface: enamel anthracite
Cleaning:
Comfort:
- Electronic clock
- Electronic clock
- heating-up control
- Full-glass inner door, Soft Close, soft opening
- Bar handle
- Rapid heating-up
- Halogen interior lighting
- Integral cooling fan
Accessory:
- 1 x combination grid, 1 x universal pan
Environment and Safety:
- Maximum window temperature 50° C
- Child lock
Technical Info:
- ER2x2 ZZ in oven (2+4)
- Nominal voltage: 220 - 240 V
- Total connected load electric: 11.2 KW
- Energy efficiency rating (acc. EU Nr. 65/2014): A(at a range of energy
efficiency classes from A+++ to D)
- Energy consumption per cycle in conventional mode:0.97 kWh
- Energy consumption per cycle in fan-forced convection mode:0.81 kWh
- Number of cavities: 1 Heat source: electrical Cavity volume:71 l
Dimensions:
- Appliance dimension (hxwxd): 595 mm x 594 mm x 548 mm
- Niche dimension (hxwxd): 600 mm - 604 mm x 560 mm - 568 mm x 550
mm
- “Please reference the built-in dimensions provided in the installation
drawing”
