RK--HKS- Quick Start (P/N: -300877QS REV 1)4U102900

P/N:

2900-300877QS

Rev:

1

Scan for full manual

RK--HKS- Quick Start Guide 4U10

This guide helps you install and use your RK--HKS-4U10for the rst time.

Go to www.kramerav.com/downloads/RK-4U-HKS-10to download the latest user manual.

Step 1: Check what’s in the b ox

1RK--HKS-4U10HighSecLabs rack mounting bracket chassis

with 10 support mounts

Screws

1 Quick start guide

Step 2: Install --- RK4UHKS10

To rack mount up to 10 units using the bracket:

1. Attach the chassis (main bracket) to the rack with 4 screws (3) (not included).

2. Insert each unit in a support mount and tighten the support mount with 4 M3-0.5x6mm screws (1). to

3. Insert the support mount with the unit into the main bracket and tighten it with the 2 M4x10mm screws (2). .

Technical Specifications

Product Dimensions:

48.6 cm x 17.7 cm x 10.2 cm (19“ x 7.0” x 4U) W, D, H

Product Weight:

3.4kg (7.5lb)

Shipping Dimensions:

51 cm x 19 cm x 17 cm (20“ x 7.5” x 6.7”) W, D, H

Shipping W: eight

3.8kg (8.4lb)

Accessories:

40 M3-0.5x6mm screws, 20 M4x10mm screws

Specifications are subject to change without notice at www.kramerav.com
