Oldal 1/12
M u l t i p u r p o s e G r i d T i e P o w e r I n v e r t e r
http://www.new-pv.comhttp://www.new-pv.com
GTN GTW /1000W 1200W &
Installation and operation manual
1
1.Manual description
1.1 product description---------------------------------------------2
2.Safety instructions and specifications
2.1 Terms of Use------------------------------------------------3
2.2 Model naming-----------------------------------------------3
3.Installation procedure
3.1 Installation to suitable place-----------------------------------4
3.2 Inverter installation -----------------------------------------4
---------------------------------54.1 Connection cable requirements
4.2 AC connection description ------------------------------------6
4. Electrical connection and commissioning
5. LCD display operation and content description
5.1 LCD main interface display content description-----------------------7
5.2 LCD anomalies prompt Description------------------------------7
6. Main technical parameters data sheet Appendix A-1000W model
8. Component connection diagram
8.1 Two serial and two parallel connections-----------------------------10
8.2 Four serial connections---------------- --------------------------------------11
Packing List -----------------------------------------------------10
Table of Contents
1.2 Packaging inspection -----------------------------------------2
2.3 Grid Tie inverter features------------------------------------3
4.3 DC terminal connection instructions ------------------------------6
4.4 Trial run ----------------------- -------------------------------6
5.3 Button setting operation instructions-----------------------------8
5.4 Main setting interface content description-------------------------8
5.5 Battery grid connection parameter setting instructions---------------8
-------9
7. Main technical parameters data sheet Appendix B-1200W model
-------9
8.3 Two serial and two parallel connect panels charging the battery------------11
Disclaimer and copyright notice ------------------------------------10
2
product description
technology, which has the same ability to serial and parallel connect multiple components in
series with a centralized inverter, while also having a distributed micro-inverter Small size and
high efficiency, built-in innovative speed-enhanced maximum power point tracking (MPPT)
control algorithm, integrated LCD function display and LED status display. The whole machine
uses a number of patented designs, with high circuit integration, reliable performance,
comprehensive optimization of the heat dissipation system, compatibility with various types of
photovoltaic panel components, easy to operate and install
The grid-connected inverter can be applied to (such as various types of photovoltaic modules,
various types of batteries, DC switching power supplies, DC motors, etc.) in the grid feed system
or power supply type of load discharge, aging test and other systems. In the photovoltaic grid-
connected inverter, the solar panel assembly can maximize the power output (built-in precision
MPPT), convert the output energy of the solar panel assembly to the grid, or use other switching
power supplies and battery discharge tests. Contact us for technical information.
1.2 Packaging inspection
Although we have carefully tested and tested the grid-connected inverter before
transportation, it is inevitable that damage may occur during transportation, so please check it
carefully before installation. If any damage is detected, please contact the shipping company or
contact us directly. Please provide a photo of the damage, we will provide you with the fastest
and best service.
2 Safety instructions and specifications
Please read this manual carefully before installation and operation. If the equipment is damaged
due to failure to install and operate according to the instructions in this manual, the company
reserves the right not to provide warranty-free service.
The GTW&N-1000W/1200W grid-tied inverter uses innovative grid-connected inverter
2.1 Specifications
a. Normal safe operation of the inverter requires proper transportation, storage, installation
and connection, as well as operation and maintenance.
b. All operations and wiring should be performed by professional mechanical and electrical
engineers, and all electrical installations must comply with local electrical installation standards.
c. Before installing or wiring, be sure to measure the DC side and AC side voltage of the device
with a voltmeter to ensure that the DC side and AC side are operated without voltage.
d. Follow all instructions for hazard, warning, and safety information in accordance with the
operating and installation instructions.
1. 1
1. Manual description
Connection diagram
Solar Array
Grid tie inverter
Electricity meter
Grid
