Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/25/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• HDMI2DPconverter

• PowerAdapter

• InstallationGuide

System Requirements

• HDMIorDVI-Denabledvideosourcedevice(i.e.computer,game

console,DVR,etc)

• DisplayPortenableddisplaydevice(i.e.monitor,projector,etc)

• AvailableACpoweroutlet

HDMI2DP

HDMI or DVI to DisplayPort Active Converter

*actual product may vary from photos

Installation

Ifthevideosourcedevicesupportshot-pluggingoftheHDMI/DVI-D

interface,thenhavingitpoweredonduringinstallationshouldwork.

Otherwise,makesureitisturnedobeforebeginninginstallation.

1. Connecttheincludedpoweradaptertothevideoconverter.The

powerLEDshouldlightupsolid.

2. Connectthevideosourcetothevideoconverterwithastandard

male/maleHDMIcableorDVI-DtoHDMIcable/adapter.

3. Connectthedisplaydevicetotheconverterwithastandardmale/

maleDisplayPortcable.

4. Turnonthedisplaydevice,followedbythevideosourcedevice,

ifnotalready.TheConnectionStatusLEDshouldlightupsolidto

indicateagoodlinkbetweenthevideosourceanddisplay.

5. Ifnovideoappearsonthedisplay,checktomakesurethevideo

sourceisoutputtingavideoresolutionthatissupportedbythe

displaydevice(i.e.1024x768).

DCPower

Connector

HDMIConnector

(input)

Power

LED

DisplayportConnector

(output)

ConnectionStatus

LED

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSA LLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

Video Signal HighSpeedHDMI(HDMI1.3b)

DisplayPort1.1a

Connectors

1xHDMItypeAfemale

1xDisplayPortfemale

1xDCPower

LEDs 1xPower

1xConnectionStatus

Maximum Video Resolution 1920x1200

EDID Support Yes

Audio Support 2-channel,uncompressed
