This product is intended for installation only by expert users. Please consult with a qualified technician for installation.

Improper installation may result in damage to your equipment.

Before you start using this product please follow these basic guidelines:

1. Please carefully read through the instruction manual before beginning the installation process.

2. Please remove your graphics card from your motherboard to insure the safest process and in order to prevent any possible damages to

your CPU and motherboard.

3. It is strongly recommended to use market proven pre-mix coolant, such as Thermaltake Coolant 1000.

a

aabb

Ax1

Bx1

C D E F H I x 13 x 4 x 7 x 6 x 6 x 2G x 1

2

Remove original VGA stock cooler (Remove

the screws circled on the diagram. All heat sink

assembly screws should be removed)

When installing the water block, carefully position the water block with the preinstalled standoffs

on the graphics card.

Remove the power connector

Parts List

8

Apply thermal compoundCut the thermal pads to the dimensions listed and place them on the spots shown on the diagram.

H

64mm

a

67

3

Clean the original thermal compound off the GPU die and remove the

screws to detach the backplate. (Carefully detach the original stock cooler

after removing all acrews securing the cooler to the board)

Finish

9

1

B

F

C

E

D

C

I

4

Remove the

power connector

5

G

64mm

a

64mm

a

97mm

b

9mm

97mm

b

9mm

More Language (Deutsch, Español, Français, Italiano, Português,

Русский简体中文, 正體中文, 日本語, , Türkçe, ภาษาไทย)

Please visit www.thermaltake.com

Support

16.8Million Colors

Pacific V-GTX 1080Ti Plus

VGA Water Block

© 2017 Thermaltake Technology Co., Ltd. All Rights Reserved.

www.thermaltake.com
