INSTALLATION MANUAL
SPEAkEr wALL MOUNTINg brAckETS
HY-wM7b, HY-wM7w
Thank you for purchasing TOA’s Speaker Wall Mounting Bracket.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. SAFETY PrEcAUTIONS
• Beforeinstallationoruse,besuretocarefullyread
all the instructions in this section for correct and
safe operation.
• Besuretofollowalltheprecautionaryinstructions
in this section, which contain important warnings
and/orcautionsregardingsafety.
• After reading, keep this manual handy for future
reference.
Indicatesapotentiallyhazardoussituationwhich,
if mishandled, could result in death or serious
personal injury.
wArNINg
• Install the speaker only in a location that can
structurally support theweight ofthe speakerand
the mounting bracket. Doing otherwise may result
inthespeakerfallingdownandcausing personal
injuryand/orpropertydamage.
• Sincethebracketisdesignedforindooruse,donot
install it outdoors. If installed outdoors, the aging
of parts causes the speaker to fall off, resulting in
personal injury. Also, when it gets wet with rain,
thereisadangerofelectricshock.
• Owing to the speaker’s size and weight, be sure
that at least two persons are available to install the
speaker.Failureto do socould result inpersonal
injury.
• Donotuseothermethodsthanspeciedtomount
thebracket.Extremeforceisappliedtothebracket
andthespeakercouldfalloff,possiblyresultingin
personal injuries.
• Use nuts and bolts that are appropriate for the
wall’s structure and composition. Failureto do so
may cause the speaker to fall, resulting in material
damageandpossiblepersonalinjury.
• Use the specied speaker and rigging bracket
in combination. Doing otherwise may cause the
speaker to fall off, resulting in personal injury.
• Tighten each nut and bolt securely. Ensure that
the bracket has no loose joints after installation
to prevent accidents that could result in personal
injury.
• Avoid installing the speaker in indoor swimming
facilities that are not well ventilated. In such
locations, the bracket may be vulnerable to
corrosion, eventually allowing the speaker to fall
resulting in personal injury.
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultin moderateor minor
personalinjury,and/orpropertydamage.
cAUTION
• Avoid touching the bracket’s sharp metal edge to
prevent injury.
• Donotplaceheavyobjectsonthebracketasthis
may cause the speaker to fall or break which may
result in personal injury and/or property damage.
Inaddition,theobjectitselfmayfalloffandcause
injuryand/ordamage.
• Do not stand or sit on, nor hang down from the
bracketasthismaycausethespeakertofalldown
ordrop,resultinginpersonalinjuryand/orproperty
damage.
• Havethebracketcheckedperiodicallybytheshop
from where it was purchased. Failure to do so
mayresultincorrosionordamagetothemounting
bracketthatcouldcausethespeakertofall,possibly
causing personal injury.
2. gENErAL DEScrIPTION
TheHY-WM7BandHY-WM7WareintendedformountingtheHX-7BorHX-7WSpeakerSystemtoindoorwalls
byusingtogetherwiththeoptionalHY-VM7BorHY-VM7WSpeakerRiggingBracket.
ModelNo. HY-WM7B HY-WM7W
Finish Steel plate, black, semi-gross, paint Steel plate, white, semi-gross, paint
Weight 5 kg (11.02 lb)
Accessory Hex head and bolt M8 x 25 with spring plain washers ....... 4
Optionalproducts HY-VM7BSpeakerRiggingBracket HY-VM7WSpeakerRiggingBracket
ProductComposition Bracket A ....... 1, Bracket B ....... 1
Note
Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.
URL:http://www.toa.jp/
133-01-00043-00
This bracket (Bracket A)
This bracket (Bracket B)
HY-VM7B or HY-VM7W
Speaker Rigging Bracket
HX-7B or HX-7W speaker
3. MOUNTINg DIAgrAMS
[component disassembly] [completed installation]
Note
OnlyoneHX-7B orHX-7W
speakercanbemounted.
Twojoinedspeakerscannot
bemounted.
For installation method, refer to the instruction
manualsuppliedwiththeoptionalHY-VM7BorHY-
VM7WSpeakerRiggingBracket.
4. SPEcIFIcATIONS
Termékspecifikációk
| Márka: | TOA |
| Kategória: | nincs kategorizálva |
| Modell: | HY-WM7W |
Szüksége van segítségre?
Ha segítségre van szüksége TOA HY-WM7W, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
