Használati útmutató WHALE Gusher 10 Mk3

Olvassa el alább 📖 a magyar nyelvű használati útmutatót WHALE Gusher 10 Mk3 (8 oldal) a nincs kategorizálva kategóriában. Ezt az útmutatót 18 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.9 csillagra

Thank you for purchasing this Whale® product.

For over 60 years Whale® has led the way in the design and manufacturer of water and waste systems

including:- plumbing, faucets, showers and pumps for low voltage applications. The company and its products have

built a reputation for quality, reliability and innovation backed up by excellent customer service.

For information on our full product range visit: www.whalepumps.com

CONTENTS

1. Principles of Operation

2. Specification

3. Application

4. Warnings

5. Parts List

6. Optional Extras

7. Installation

8.Maintenance

9. Trouble Shooting

10. Winterising

11. Service Support Details

12. EU Declaration of Conformity

13. Patents and Trademarks

14. Warranty

LIST OF IMAGES

Fig. 1Through deck installation

Fig. 2Incorrect installation

Fig. 3 Typical installation diagram

Fig. 4 Mounting arrangements for a standard model

Fig. 5 Dimensions

Fig. 6Discharge point is well above the water line

Fig. 7 Deck fitting for Gusher Pumps (Half sectional elevation of deck fitting, pump and bracket)

Fig. 8 Exploded diagram

Read the following carefully before installation

To the Fitter:

Check that the product is suitable for the intended application. Follow these installation instructions and ensure all

relevant personnel read the points listed below. Also ensure that these operating instructions are passed on to the

end user. The manufacturer cannot be held responsible for claims arising from incorrect installation, unauthorised

modification or misuse of the product.

To the User:

Read the following instructions carefully.

Whale Gusher

®

10 Mk3 PumpBP3708 / BP3740

INSTALLATION & USER INSTRUCTIONS

1

Termékspecifikációk
