EVA-221X LoRaWAN 3-Phase Current Meter
Startup Manual
Thank you for purchasing the EVA-22 LoRaWAN 3-Phase 1X
Current Meter. This quick start guide is intended to help you
deploy your new sensor. The guide contains basic informaon on
the power and applicaon wiring. Should you require addional
instrucons, please refer to the user manual.
E - is designed for 2 3.6V AA Lithium Baeries VA 221X
1 x EVA- Sensor 221X
1 x Quick start manual
1.
EVA- runs OTAA mode, please have the AppKEY, 221X
AppEUI and DeviceEUI in the QR-Code below.
For more informaon on this and other Advantech products,
please visit our website at:
hp://www.advantech.com
For technical support and service:
hps://www.advantech.com/support/
The startup manual is for EVA- product.221X
Printed in China
1st Edion
Nov 2023
2.
Default EVA- frequency plan denions below for 221X
reference
Uplink plan:
Frequency
Common Name
Uplink Plan(MHz) Frequency
US915
903.9, 904.1, 904.3, 904.5,
904.7, 904.9, 905.1, 905.3
904.6(@BW500)
EU868
868.1, 868.3, 868.5, 867.1
867.3, 867.5, 867.7, 867.9
868.8(@FSK)
AU915
915.2, 915.4, 915.6, 915.8,
916.0, 916.2, 916.4, 916.6
915.9(@BW500)
AS923
923.2, 923.4
Downlink Frequency plan:
Common Name
Downlink Plan(MHz) Frequency
US915
923.3, 923.9, 924.5, 925.1,
925.7, 926.3, 926.9, 927.5(RX1)
923.3(RX2)
EU868
868.1, 868.3, 868.5, 867.1
867.3, 867.5, 867.7, 867.9 (RX1)
869.525 SF12BW125 (RX2) –
AU915
923.3, 923.9, 924.5, 925.1,
925.7, 926.3, 926.9, 927.5(RX1)
923.3(RX2)
AS923
923.2, 923.4 (RX1)
923.2 SF10BW125(RX2) –
3.
Open the front cover and install 2 3.6V AA lithium
baeries on baery holder.
EVA- Startup Manual 1 221X
Overvie
Overvie
Overvie
OvervieOverview
w
w
w w
Quic
Quic
Quic
QuicQuick Start
k Start
k Start
k Start k Start
Inpu
Inpu
Inpu
InpuInput Power Requi
t Power Requi
t Power Requi
t Power Requit Power Requirement
rement
rement
rementrement
Packag
Packag
Packag
PackagPackaging List
ing List
ing List
ing List ing List
4.
Press the buon for 3 seconds for powering on the
device. You will see the LED quick blink one me.
Once the device connect to your LoRaWAN Network
Server successfully, the LED will on for 5 seconds.
Note: Buon and LED behavior below for reference.
Buon Press
LED Behavior
Funcon
Quick Press
Quick blink for
one me
Force TX
Press for 3 secs
Quick blink for
one me
Power On
Press for 5 secs
Quick blink for
20 mes
System o and
reset to default
-
On for
5 Seconds
OTAA Join
Success
5.
Default data update cycle of EVA-221X is 3600 seconds. You
can change the data update cycle directly from WISE-6610,
Advantech LoRaWAN Gateway, or via a downlink command
from your service.
6.
The CT sample rate is 8kHz. EVA-221X will get the current
data from CT for 3 second, and calculate the RMS next.
7.
EVA- has 3 mounng style which includes wall mount, 221X
magnec mount and pole mount.
Wall Mount Magnec Mount
Pole Mount
1.
Please do keep this start manual securely since the information
of AppKEY, AppEUI and DeviceEUI shows in this manual only.
2.
Keep the device dry. Rain, moisture, or any liquid might contain
minerals and thus corrode electronic circuits. If the device gets
wet, please dry it completely.
3.
Do not use or store the device in dusty or dirty environment. It
might damage its detachable parts and electronic components.
4.
Do not store the device under excessive heat condion. High
temperature can shorten the life of electronic devices, destroy
baeries, and deform or melt some plasc parts.
5.
Do not store the device in places that are too cold. Otherwise,
when the temperature rises to normal temperature, moisture
will form inside, which will destroy the board.
6.
Do not throw, knock or shake the device. Rough handling of
equipment can destroy internal circuit boards and delicate
structures.
7.
Do not clean the device with strong chemicals, detergents or
strong detergents.
8.
Do not apply the device with paint. Smudges might block in the
device and aect the operaon.
9.
Do not throw the baery into the re, or the baery will
explode. Damaged baeries may also explode.
EVA- Startup Manual 2 221X
Caution
Caution
Caution
CautionCaution
