www.agmglobalvision.com

©2019 AGM Global Vision. All rights reserved.

173 West Main Street PO Box 962 Springerville, AZ 85938||

Tel. 928.333.4300 info@agmglobalvision.com||Fax 480.393.4882

The AGM 7x50 daytime binoculars offer 7x magnification,

waterproof construction, and a built-in range finding reticle. It is

purposed for military, law enforcement or outdoor adventurer’s

needs.

The AGM binoculars provide powerful magnification and crystal

clear optics that deliver a full range of color and clarity. The

multi-coated optics of the binoculars are designed to enhance

the resolution and contrast of your image in extremely bright

conditions. The built-in universal range finder allows for accurate

target measurements and range estimates.

Package Includes:

Binocular, Lens Cap, Eye-Cap, Neck Strap, Operation and

Maintenance Manual, Soft Carrying Case

DAYTIME BINOCULARS

7X50

Magnification7x

Prisms systemPorro / Bak-4

Number of Elements & Groups7 pieces in 5 groups

Objective lens diameter50mm

FOV (angular)7.5°

FOV at 1000 m / 1000 yd131 m / 393 ft

Minimum Focus Distance9.8 m

Exit pupil 7.1 mm

Eye relief22.8 mm

Relative Brightness50,4

Twilight Factor18,7

Resolution ≤ 4.5”

Relative brightness50.4

Focus SystemIndividual

Diopter Adjustment-5 to +5 dpt

Interpupillary Distance56 to 72 mm

Eye Cups TypeFold down Eyecups

Body Housing MaterialStrengthened PVC

Waterproof0.5 m for 30 min

Nitrogen FilledYes

Weight1.4 kg (3.0 lbs)

Size200 × 150 × 85 mm (7.9 ×5.9 × 3.3 in)

Tripod mountYes

■

Powerful magnification

■

Designed for professional use

■

Built-in universal rangefinder

■

Multi-coated optics

■

Full rubber body armoring

■

Individual eye focus

■

Limited 3-Year Warranty

Specifications are subject to change without notice.

Images are for illustration purposes only.
