Oldal 1/15
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: +49 (0) 511 16 59 672-0 · www.akytec.de
SMI200
Programmable compact controller
User guide
SMI20 _201 0275 _EN0 9 6_.0
© All rights reserved
Subject to technical changes and misprints
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Ha over · Germany · .: +49 (0) 511 16 59 672nn Tel -0 · www.akytec.de
1
1
Contents
1 Overview.......................................................................................................................................................... 2
1.1 Functions ................................................................................................................................................. 2
1.2 Design ...................................................................................................................................................... 2
2 Specifications ................................................................................................................................................. 3
2.1 Environmental conditions ......................................................................................................................... 3
3 Safety............................................................................................................................................................... 4
3.1 Safety symbols and key words ................................................................................................................ 4
3.2 Intended use ............................................................................................................................................ 4
4 Installation....................................................................................................................................................... 5
4.1 cautions Safety pre ................................................................................................................................... 5
4.2 Wiring ....................................................................................................................................................... 5
5 Display and function buttons ........................................................................................................................ 7
6 System menu .................................................................................................................................................. 8
7 Operation....................................................................................................................................................... 10
7.1 RUN- STOP ............................................................................................................................................ 10
7.2 Down.Mode ............................................................................................................................................ 11
8 Maintenance.................................................................................................................................................. 12
9 Transportation and storage ......................................................................................................................... 13
10 Scope of delivery .......................................................................................................................................... 14
Overview
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Ha over · Germany · .: +49 (0) 511 16 59 672nn Tel -0 · www.akytec.de
2
1 Overview
SMI20 2- - 0 is a programmable controller with line 32 character LCD display designed for a wide vari-
ety of applications automation from simple display to complex process in industrial and building
control functions.
The controller can operate as a master or slave in a Modbus network over RS485 interface In or-.
der to in a Modbus network, the controller has to be configured and programmed with be integrated
the akYtec ALP software included on the USB stick.
See ALP Help for further details about device configuration and programming.
The configuration can be carried out with device front buttons over the system menu as well (see
sections 5, 6).
The connection with akYtec ALP running on the PC can be established over the USB interface
(Fig. 1.1). When being con over USB, the device is powered by USB and does not nected to PC
need additional power supply.
User application includes the logic program created as a function plan as well as the device config-
uration.
1.1 s Function
The device has the following basic functions:
– 2- - line 32 character LCD display
– 6 function buttons on the front panel
– Master or slave in a Modbus network over RS485 interfaceRTU/ASCII
– Ø Easy mounting in 22.5 mm borehole
– Error indication
– - Real time clock
– Free programming with akYtec ALP software
– - Micro USB programming interface
– Quick replacement
1.2 Design
The device is designed in a plastic enclosure mounting (see 4 “ for panel Installation” ).
Fig. 1.1
1. LCD display
2. Function buttons
3. socket - Micro USB
4. 4-pole p in terminal blocklug-
For further details about using the display and function buttons see section 5 “Display and function
buttons”.
