Oldal 1/124
ARC-8050T2
(Thunderbolt 2 to 6Gb/s SAS RAID Storage)
User Manual
Version: 2.2
Issue Date: December, 2014
Thunderbolt™ Prod
uct
Copyright and Trademarks
The information regarding products in this manual is subject to change
without prior notice and does not represent a commitment on the part
of the vendor, who assumes no liability or responsibility for any errors
that may appear in this manual. All brands and trademarks are the
properties of their respective owners. This manual contains materials
protected under International Copyright Conventions. All rights
reserved. No part of this manual may be reproduced in any form or by
any means, electronic or mechanical, including photocopying, without
the written permission of the manufacturer and the author.
FCC Statement
This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against in-
terference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation.
Manufacturer’s Declaration for CE Certication
We conrm ARC-8050T2 has been tested and found comply with the
requirements set up in the council directive on the approximation of
the low of member state relating to the EMC Directive2004/108/EC.
For the evaluation regarding to the electromagnetic compatibility, the
following standards where applied:
EN 55022: 2006, Class B
EN 61000-3-2: 2006
EN 61000-3-3: 1995+A1: 2001+A2: 2005
EN 55024:1998+A1:2001=A2:2003
IEC61000-4-2: 2001
IEC61000-4-3: 2006
IEC61000-4-4: 2004
IEC61000-4-5: 2005
IEC61000-4-6: 2006
IEC61000-4-8: 2001
IEC61000-4-11: 2004
Contents
1. Introduction ................................................................ 8
1.1 Overview .........................................................................8
1.2 Features ........................................................................ 10
2. Installation ................................................................ 12
2.1 Before You First Installing................................................. 12
2.2 Summary of RAID Storage Setup Steps .............................. 13
• For Mac OS X ................................................................. 13
• For Windows .................................................................. 13
2.3 RAID Storage View .......................................................... 15
2.4 Locations of the Storage Component .................................. 16
2.4.1 Drive Tray LED Indicators ............................................ 16
2.4.2 LCD Panel LED Indicators ............................................ 17
2.4.3 Thunderbolt Port LED Indicators ................................... 17
2.5 Setting Up RAID Storage .................................................. 18
2.5.1 Physically Install RAID Storage and Drives ..................... 18
2.5.2 Mac Users ................................................................. 22
2.5.2.1 Install the MRAID Software ..................................... 22
2.5.2.2 Congure RAID Volumes ......................................... 26
2.5.2.3 Format RAID Volumes ............................................ 29
2.5.2.4 Make A Bootable RAID Volume ................................ 31
2.5.2.5 Unmounting RAID Volumes ..................................... 31
2.5.3 Windows Users .......................................................... 32
2.5.3.1 Install the MRAID Software ..................................... 32
2.5.3.2 Congure RAID Volumes ......................................... 36
2.5.3.3 Format RAID Volumes ............................................ 39
2.5.3.4 Unmounting RAID Volumes ..................................... 39
3. ArcHTTP Conguration .............................................. 41
• General Conguration ..................................................... 41
• Mail (Alert by Mail) Conguration ..................................... 42
• SNMP Traps Conguration ............................................... 43
• Rescan Device Conguration ............................................ 45
• Collect Support Data ...................................................... 45
4. Web Browser-based Conguration ........................... 46
4.1 Start-up McRAID Storage Manager .................................... 47
• McRAID Storage Manager from Local Administration (In-Band)
...................................................................................... 47
• McRAID Storage Manager Through LAN Port (Out-of-Band) .. 48
