Oldal 1/2

EAN 9347777005229

PRODUCT INFORMATION

FINISH

• WhiteSchottglass

FEATURES

• 9heatlevels

• IndividualTimerupto99minutes

• Touchcontrol

• Pansensor

• Indicatorlightcolour:red

SAFETY

• Automaticsafetycut-o

• Residualheatindicators

• Childlock

ZONES

• 4inductionzones

•  2x180Ø1500W+boost2000W(frontleft&rearright)

•  2x140Ø1200W+boost1500W(Rearleft&frontright)

TECHNICAL

• Seepage2

MODEL CAID6000W

60cm Induction Cooktop

AR01112023

artusi.com.au

48-50 Moore Street

Leichhardt

F 02 8569 4699

2r/131 Church Street

Hawthorn

Contact Head Ofce Contact Head Ofce

DIS CLA IMER

Eurolinx PTY LTD, is continually seeking ways to improve the design specications, aesthetics and production techniques of its products. As a result alterations

to our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be

regarded as an infallible guide to the current specications, nor does it constitute an offer for the sale of any particular product. Product dimensions indicated in

our literature is indicative only. Actual product only should be used to dene dimension cut outs. Distributors, and retailers are not agents of Eurolinx and are not

authorised to bind Eurolinx by any express or implied undertaking or representation.

Australia National Telephone Number 1300 694 583

For showroom opening times, visit our website

/artusi_kitchen_laundry_outdoor

Technical Information CAID6000W Built-in Cooktop

Size 590 x 520 x 62 (incl. glass) CUTOUT 560 x 490

Electrical Connection: Hard Wired, 220–240V,

Total Power(W): 5400

Single or double phase

TECHNICAL DIAGRAM
