DATA SHEET

Multi-functional 360 Series 802.11ac Wave 2

outdoor access points deliver cost-eective

wireless connectivity to mobile and IoT devices

in a wide range of outdoor and warehouse

environments.

With a maximum aggregate data rate of 1.2 Gbps (1.167

Gbps), the 360 Series comes with multi-user MIMO (MU-

MIMO), 2 spatial streams (2SS), and optional 80MHz channel

bandwidth (VHT80) to quickly add performance and capacity

to existing or wireless networks.

EXTREME WEATHER RESILIENCY

Able to survive in harsh outdoor environments and provide

connectivity in warehouses and distribution centers, the 360

Series can withstand exposure to high and low temperature

extremes, wind speeds up to 165 mph, and tolerate

persistent moisture, precipitation, and dust and salt sprays

for extended periods of time. All electrical interfaces include

industrial strength surge protection.

MU-MIMO AWARE CLIENT OPTIMIZATION

The 360 Series includes Aruba’s patented ClientMatch

technology to eliminate sticky client issues while optimizing

802.11ac Wave 2 performance. These APs continuously

gather session performance metrics to steer mobile devices

to the best-available AP - even while users roam. With MU-

MIMO awareness, ClientMatch can group MU-MIMO capable

devices together to increase network capacity and eciency.

ClientMatch also participates in Aruba’s AI-powered Mobility

solution.

IOT-READY

The 360 Series includes an integrated Bluetooth Low Energy

radio to simplify the deployment and management of

location services, asset tracking services, security solutions

and IoT sensors. This allows organizations to leverage the

360 Series as an IoT platform, which eliminates the need for

an overlay infrastructure and additional IT resources.

ARUBA 360 SERIES

OUTDOOR ACCESS POINTS

Entry-level outdoor and warehouse connectivity

with Wi-Fi 5 (802.11ac Wave 2)

ARUBA SECURE INFRASTRUCTURE

The Aruba 360 Series includes components of Aruba’s

360 Secure Fabric to help protect user authentication and

wireless trac. Select capabilities include:

WPA3 and Enhanced Open

Support for stronger encryption and authentication is

provided via the latest version of WPA for enterprise

protected networks.

Enhanced Open oers seamless new protection for users

connecting to open networks where each session is

automatically encrypted to protect user passwords and data

on guest networks.

WPA2-MPSK

MPSK enables simpler passkey management for WPA2

devices – should the Wi-Fi password on one device or device

type change, no additional changes are needed for other

devices. Requires ClearPass Policy Manager.

VPN Tunnels

In Remote AP (RAP) and IAP-VPN deployments, the Aruba

360 Series can be used to establish a secure SSL/IPSec

VPN tunnel to a Mobility Controller that is acting as a VPN

concentrator.

KEY FEATURES

• Deliver gigabit Wi-Fi to outdoor and extreme

environments.

• 1.2 Gbps of maximum throughput

• WPA3 and Enhanced Open security

• Patented ClientMatch technology resolves sticky

client issues and optimizes Wave 2 performance

• AI-powered AirMatch automates RF optimization

• IoT-ready with integrated Bluetooth Low Energy

(BLE)

• Participates in Aruba’s Dynamic Segmentation

solution

DATA SHEET

ARUBA 360 SERIES OUTDOOR ACCESS POINTS

Trusted Platform Module (TPM)

For enhanced device assurance, all Aruba APs have an

installed TPM for secure storage of credentials and keys, and

boot code.

SIMPLE AND SECURE ACCESS

To simplify policy enforcement, the Aruba 360 Series

uses Aruba’s policy enforcement rewall (PEF) feature

to encapsulate all trac from the AP to the Mobility

Controller (or Gateway) for end-to-end encryption and

inspection. Policies are applied based on user role, device

type, applications, and location. This reduces the manual

conguration of SSIDs, VLANs and ACLs. PEF also serves as

the underlying technology for Aruba Dynamic Segmentation.

FLEXIBLE OPERATION AND MANAGEMENT

A unique feature of Aruba APs is the ability to operate in

either controllerless (Instant) or controller-based mode.

Controller-less (Instant) mode

In controllerless mode, one AP serves as a virtual controller

for the entire network. Learn more about Instant mode in

this technology brief.

Mobility Controller mode

For optimized network performance, roaming and security,

APs tunnel all trac to a mobility controller for centrally

managed trac forwarding and segmentation, data

encryption, and policy enforcement. Learn more in the

ArubaOS datasheet.

Management options

Available management solutions include Aruba Central

(cloud-managed) or Aruba AirWave – a multi-vendor on-

premises management solution.

For large installations across multiple sites, APs can be

factory-shipped and can be activated with Zero Touch

Provisioning through Aruba Central or AirWave. This reduces

deployment time, centralizes conguration, and helps

manage inventory.

ADDITIONAL FEATURES

Zero Touch Provisioning

APs can be factory-shipped and zero-touch provisioned

through Aruba Central or AirWave using a cloud-based

service to reduce deployment time, centralize conguration,

and manage inventory.

Advanced Cellular Coexistence (ACC)

Minimizes interference from 3G/4G LTE cellular networks,

distributed antenna systems (DAS), and commercial small cell

or femtocell equipment

Hardened, industrial design

Extends the temperature range capabilities of indoor access

points for environments that lack heating and cooling. It also

provides sealed connector interfaces to protect against dust

and moisture

AP-360 SERIES SPECIFICATION

• AP-365

-2.4-GHz (300 Mbps max) and 5-GHz (867 Mbps max)

radios, each with 2x2 MIMO and integrated omni-

directional antennas.

• AP-367

-2.4-GHz (300 Mbps max) and 5-GHz (867 Mbps max)

radios, each with 2x2 MIMO and integrated

directional antennas.

WIRELESS RADIO SPECIFICATIONS

• AP type: outdoor, dual radio, 5 GHz 802.11ac and

2.4 GHz 802.11n

• 2x2 MIMO with two spatial streams and up to 1,266 Mbps

wireless data rate

• Supported frequency bands (country-specic

restrictions apply):

-2.4000 GHz to 2.4835 GHz

-5.150 GHz to 5.250 GHz

-5.250 GHz to 5.350 GHz

-5.470 GHz to 5.725 GHz

-5.725 GHz to 5.875 GHz

• Available channels: Dependent upon congured

regulatory domain

• Dynamic Frequency Selection (DFS) compliant to radar

coexistence requirements

• Supported radio technologies:

-802.11b: Direct-sequence spread-spectrum (DSSS)

-802.11a/g/n/ac: Orthogonal frequency-division

multiplexing (OFDM)

-802.11n/ac: 2x2 MU-MIMO with up to two spatial streams

• Supported modulation types:

-802.11b: BPSK, QPSK, CCK

-802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM

-802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM

• Transmit power: Congurable in increments of 0.5 dBm

DATA SHEET

ARUBA 360 SERIES OUTDOOR ACCESS POINTS

• Maximum (conducted aggregate) transmit power

(limited by local regulatory requirements):

-2.4-GHz band: +26 dBm (23 dBm per chain)

-5-GHz bands: +25 dBm (22 dBm per chain)

• Maximum EIRP (limited by local regulatory requirements):

-2.4 GHz band

> 365 28.7 dBm EIRP

> 367 32.3 dBm EIRP

-5 GHz Band

> 365 29.3 dBm EIRP

> 367 31.5 dBm EIRP

• Advanced cellular coexistence (ACC) feature to eectively

deal with interference from cellular systems

• Maximum ratio combining (MRC) for improved

receiver performance

• Cyclic delay diversity (CDD) for improved downlink

RF performance

• Short guard interval for 20-MHz, 40-MHz and 80-MHz channels

• Space-time block coding (STBC) for increased range and

improved reception

• Low-density parity check (LDPC) for high-eciency error

correction and increased throughput

• Transmit beam-forming (TxBF) for increased reliability in

signal delivery

• 802.11ac wave 2 MU-MIMO

• Supported data rates (Mbps):

-802.11b: 1, 2, 5.5, 11

-802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54

-802.11n: 6.5 to 300 (MCS0 to MCS15)

-802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2)

• 802.11n high-throughput (HT) support: HT 20/40

• 802.11ac very high throughput (VHT) support: VHT 20/40/80

• 802.11n/ac packet aggregation: A-MPDU, A-MSDU Power

• Maximum power consumption: 12.5 watts

• Power over Ethernet (PoE): 48 Vdc (nominal)

802.3af-compliant source

ANTENNAS

Supports 802.11ac TxBF which provides an eectively innite

variety of antenna patterns

• AP-365: Integrated Omni antennas (H and V polarized)

-2.7 dBi @ 2.4 GHz

-4.3 dBi @ 5.x GHz

• AP-367: Integrated Directional antennas (+/-45 polarized)

-6.3 dBi @ 2.4 GHz (90° Vertical x 90° Horizontal)

-6.5 dBi @ 5.x GHz (90° Vertical x 100° Horizontal)

OTHER INTERFACES

• One 10/100/1000BASE-T Ethernet network interfaces (RJ-45)

-Auto-sensing link speed and MDI/MDX

-802.3az Energy Ecient Ethernet (EEE)

-PoE-PD: 802.3af PoE

• Serial console interface (micro USB)

• Reset button

• Visual indicator (LED):

-Power/system status

MOUNTING

• Ordered separately

• Optional mounting kits:

-AP-OUT-MNT-V1A: Outdoor Pole/Wall Long Mount Kit

-AP-270-MNT-V2: Outdoor Pole/Wall Short Mount Kit

-AP-270-MNT-H1: Outdoor AP Hanging or Tilt Install Mount

Kit

-AP-270-MNT-H2: Outdoor Flush Wall or Ceiling Mount

-AP-270-MNT-H3: Outdoor AP Hanging or Dual-Tilt Install

Mount Kit

MECHANICAL

• Dimensions/weight (unit, excluding mount accessories):

-165mm (W) x 165mm (D) x 110mm (H),

6.5” (W) x 6.5” (D) 4.3” (H)

-807g/1.78lbs (AP-365)

-815g/1.80lbs (AP-367)

• Dimensions/weight (shipping):

-198mm (W) x 200mm (D) x 128mm (H),

7.8” (W) x 7.9” (D) x5.0” (H)

-1,115g/2.46lbs (AP-365)

-1,123g/2.48lbs (AP-367)

ENVIRONMENTAL

• Operating:

-Temperature: -40° C to +55° C (-40° F to +131°F)

ambient in full sun

-Humidity: 5% to 95% non-condensing

• Max Elevation 3000m

• Storage and transportation:

-Temperature: -40° C to +70° C (-40° F to +158°F)

-EN 300 019 Storage and Transportation

• Shock, vibration, and earthquake

-IEC 60068-2-64/-27/-6
