INSTALLATION INSTRUCTIONS

99-3010S

U.S. Patent # D639,794

Attention!With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

KIT FEATURES

• DIN radio provision with pocket

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Painted silver to match the factory finish

KIT COMPONENTS

• A) Radio trim panel with climate controls • B) Radio housing • C) Pocket • D) ISO DDIN brackets • E) ISO DDIN trim plate • F) ISO trim plate

• G) ISO brackets • H) Axxess interface and harness (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 9/32” socket wrench • T-20 Torx screwdriver

• Cutting tool

TABLE OF CONTENTS

Dash Disassembly ...............................................2-3

Kit Preparation .......................................................3

Kit Assembly

–DIN radio provision with pocket ........................4

–ISO DIN radio provision with pocket ..................4

–ISO DDIN radio provision .....................................5

Axxess Interface Installation .................................6

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Axxess interface included

Antenna Adapter: 40-EU55 (sold sep.)

Steering wheel control interface: ASWC-1 (sold sep.)

Backup camera retention: BACKUPCAM-2 (sold sep.)

ABCE

G

D

F

Chevrolet Camaro 2010-2015

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

specific applications
