AX-AB-LX2

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 7/15/20 INSTAX-AB-LX2

Attention!Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Amplifier Location & Connections

-13 Speaker .............................................................2

-14 Speaker .............................................................3

Lexus IS 300 Amplifier Bypass Harness

2006-2009

Factory amp must stay plugged into vehicle in order for your factory

HVAC to work. When using the bypass harness only unplug connectors

that correspond with the amp bypass being used. All other remaining

plugs must stay plugged in with amp and remain in vehicle.

Refer to the following pages for the vehicle specific instructions for

wiring connections. Wiring connections vary per amplifier design.

There is a 13 speaker system, and a 14 speaker system.

If it’s uncertain whether the vehicle contains a specific speaker or not,

test the wires with a tone generator, or check to see if the factory

wires are populated on the vehicle side. Alternatively, the wires can

be tested for impedance with a multimeter.

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date

vehicle specific applications
