AX-LOC2.2-LD

INSTALLATION INSTRUCTIONS

MetraOnline.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 8/21/23 INSTAX-LOC2.2-LD

TABLE OF CONTENTS

Quick Start Guide

Things to Know2 .................................................

Connections .......................................................2

Gain setup

Basic setup3 .........................................................

Advanced Setup3 ................................................

Feature Breakdowns4 .............................................

Quick Reference5 .....................................................

Diagram6 ..................................................................

Specifications7 .........................................................

Premium Active LOC with Line Driver 2 IN - 2 OUT with Line Driver, Max Input 40v

TOOLS RECOMMENDED

• Digital Multi-meter

• Test Tones

Universal Premium LOC with Line Driver

The Axxess AX-LOC2.2-LD is an LOC and line driver all-in-one package. This unit allows you to add aftermarket amplifiers to your factory system

easily. High level inputs mean you can tap right into your factory speaker wire for signal, and the built-in signal sensing turns the unit on without

the need to find a factory accessory lead. In applications where a low level RCA output needs amplified the built in line driver is exactly what you

need to achieve the output you are looking for. It also provides you with a remote turn on output to your amplifier.

AX-LOC2.2-LD

Line Out Converter (LOC)

COMPONENTS

AX-L0C2.2-LD

L LINE IN RR OUTPUT L

SPEAKER IN

AX-RM1
