AX-SSO

I N S T A L L A T I O N I N S T R U C T I O N S

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun, solder,

and heat shrink • Tape • Wire cutter • Zip ties

• Micro-B USB cable

(Axxess part number )USB-MINI-CAB

TABLE OF CONTENTS

Introduction............................................................2

Programming .........................................................3

Connections ........................................................4-6

Operation ................................................................7

Ford/Chrysler Stop/Start Override Interface

2015-Up

APPLICATIONS

• Allows the override of the STOP/START engine feature

• The factory STOP/START button can resume the STOP/START feature

• Can be used with either a factory or aftermarket radio

•

Vehicle type conﬁgured through the Axxess Updater software program

• Simple 4-wire installation

Chrysler

Paciﬁca 2017

Dodge

Durango 2016-Up

Ford

Edge 2015-Up

Escape 2017-Up

F-150 2015-Up

Focus 2016-Up

Fusion 2015-Up

Jeep

Cherokee 2016-Up

Gladiator 2020-Up

Grand Cherokee 2015-Up

Wrangler 2019-Up

• AX-SSO interface

• AX-SSO harness

INTRODUCTION

The AX-SSO is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been cycled. The AX-SSO will work with either an

aftermarket radio, or a factory radio. A simple 4-wire installation is all that is required to install the device in the vehicle, and programming through a Windows 10 computer via the

Axxess Updater software program.
