AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
Steering Wheel Control Harness
Fits Select Subaru Models 2013-2014
Steering Wheel Control Harness
Fits Select Subaru Models 2013-2014
Arnés de control del volante
Compatible con modelos Subaru selectos 2013-2014
Arnés de control del volante
Compatible con modelos Subaru selectos 2013-2014
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
* Visit
AxxessInterfaces.com
for more detailed information about the
product and up-to-date vehicle specific applications
* Visit
AxxessInterfaces.com
for more detailed information about the
product and up-to-date vehicle specific applications
* Visite AxxessInterfaces.com para obtener información más detallada sobre el
producto y aplicaciones actualizadas específicas para vehículos.
* Visite AxxessInterfaces.com para obtener información más detallada sobre el
producto y aplicaciones actualizadas específicas para vehículos.
AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
Metra recommends MECP
certified technicians
Connections
• Connect the Black wire to chassis ground, and also to the Black wire from the AXCSD-6V.
• Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire from the AXCSD-6V.
• If retaining steering wheel controls: connect the Red wire labeled “AXSWC 12V Accessory” to
accessory power.
• Connect the Green/Purple wire to the reverse wire from the radio, and also to the Blue/White
wire from the AX CAM6V.
• Connect the Yellow RCA jack to the backup camera input from the radio.
• If retaining the factory AUX-IN jack, connect the Red and White RCA jacks to the AUX input
from the radio.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires
:
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Light Green wire to the parking brake wire.
Installation
1.
After the radio has been tested and verified working properly, remove the key from the ignition.
Connect the AXBUCS-SB286V2 harness to the wiring harness in the vehicle, then to the AXSWC.
2. Refer to the AXSWC instructions for radio connections and programming. Disregard the harness
that comes with the AXSWC.
Metra recommends MECP
certified technicians
Connections
• Connect the Black wire to chassis ground, and also to the Black wire from the AXCSD-6V.
• Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire from the AXCSD-6V.
• If retaining steering wheel controls: connect the Red wire labeled “AXSWC 12V Accessory” to
accessory power.
• Connect the Green/Purple wire to the reverse wire from the radio, and also to the Blue/White
wire from the AX CAM6V.
• Connect the Yellow RCA jack to the backup camera input from the radio.
• If retaining the factory AUX-IN jack, connect the Red and White RCA jacks to the AUX input
from the radio.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires
:
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Light Green wire to the parking brake wire.
Installation
1.
After the radio has been tested and verified working properly, remove the key from the ignition.
Connect the AXBUCS-SB286V2 harness to the wiring harness in the vehicle, then to the AXSWC.
2. Refer to the AXSWC instructions for radio connections and programming. Disregard the harness
that comes with the AXSWC.
Metra recommends MECP
certified technicians
Connections
• Connect the Black wire to chassis ground, and also to the Black wire from the AXCSD-6V.
• Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire from the AXCSD-6V.
• If retaining steering wheel controls: connect the Red wire labeled “AXSWC 12V Accessory” to
accessory power.
• Connect the Green/Purple wire to the reverse wire from the radio, and also to the Blue/White
wire from the AX CAM6V.
• Connect the Yellow RCA jack to the backup camera input from the radio.
• If retaining the factory AUX-IN jack, connect the Red and White RCA jacks to the AUX input
from the radio.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires
:
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Light Green wire to the parking brake wire.
Installation
1.
After the radio has been tested and verified working properly, remove the key from the ignition.
Connect the AXBUCS-SB286V2 harness to the wiring harness in the vehicle, then to the AXSWC.
2. Refer to the AXSWC instructions for radio connections and programming. Disregard the harness
that comes with the AXSWC.
Metra recommends MECP
certified technicians
Connections
• Connect the Black wire to chassis ground, and also to the Black wire from the AXCSD-6V.
• Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire from the AXCSD-6V.
• If retaining steering wheel controls: connect the Red wire labeled “AXSWC 12V Accessory” to
accessory power.
• Connect the Green/Purple wire to the reverse wire from the radio, and also to the Blue/White
wire from the AX CAM6V.
• Connect the Yellow RCA jack to the backup camera input from the radio.
• If retaining the factory AUX-IN jack, connect the Red and White RCA jacks to the AUX input
from the radio.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires
:
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Light Green wire to the parking brake wire.
Installation
1.
After the radio has been tested and verified working properly, remove the key from the ignition.
Connect the AXBUCS-SB286V2 harness to the wiring harness in the vehicle, then to the AXSWC.
2. Refer to the AXSWC instructions for radio connections and programming. Disregard the harness
that comes with the AXSWC.
AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
AXBUCS-SB286V2 AXBUCS-SB286V2
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
REV. 6/19/25 REV. 6/19/25© COPYRIGHT 2025 METRA ELECTRONICS CORPORATION © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
Steering Wheel Control Harness
Fits Select Subaru Models 2013-2014
Steering Wheel Control Harness
Fits Select Subaru Models 2013-2014
Arnés de control del volante
Compatible con modelos Subaru selectos 2013-2014
Arnés de control del volante
Compatible con modelos Subaru selectos 2013-2014
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
* Visit
AxxessInterfaces.com
for more detailed information about the
product and up-to-date vehicle specific applications
* Visit
AxxessInterfaces.com
for more detailed information about the
product and up-to-date vehicle specific applications
* Visite AxxessInterfaces.com para obtener información más detallada sobre el
producto y aplicaciones actualizadas específicas para vehículos.
* Visite AxxessInterfaces.com para obtener información más detallada sobre el
producto y aplicaciones actualizadas específicas para vehículos.
Termékspecifikációk
| Márka: | AXESS |
| Kategória: | nincs kategorizálva |
| Modell: | AXBUCS-SB286V2 |
Szüksége van segítségre?
Ha segítségre van szüksége AXESS AXBUCS-SB286V2, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók nincs kategorizálva AXESS
11 Január 2025
28 December 2024
28 December 2024
28 December 2024
28 December 2024
10 Szeptember 2024
4 Szeptember 2024
4 Szeptember 2024
4 Szeptember 2024
4 Szeptember 2024
Útmutatók nincs kategorizálva
- nincs kategorizálva Sinus Live
- nincs kategorizálva Hensel
- nincs kategorizálva Mosconi
- nincs kategorizálva Vent-A-Hood
- nincs kategorizálva Kramer
- nincs kategorizálva Carnielli
- nincs kategorizálva Tannoy
- nincs kategorizálva Graff
- nincs kategorizálva Act
- nincs kategorizálva Total
- nincs kategorizálva Ondis24
- nincs kategorizálva Maico
- nincs kategorizálva Bliss Hammocks
- nincs kategorizálva Four Hands
- nincs kategorizálva Omega Altise
Legújabb útmutatók nincs kategorizálva
10 Április 2025
10 Április 2025
10 Április 2025
9 Április 2025
9 Április 2025
9 Április 2025
9 Április 2025
9 Április 2025
9 Április 2025
9 Április 2025
