AXDI-CH13

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 9/11/19 INSTAXDI-CH13

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections .........................................................2-3

Installation .............................................................3

Programming .........................................................3

Chrysler CAN Data Interface 2004-Up

APPLICATIONS

See inside front cover

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and speed sense)

• Prewired AXSWC harness (AXSWC sold separately)

• Can be used in both amplified and non-amplified models

• Retains balance and fade (non-amplified models only)

• Micro-B USB updatable

• AXDI-CH13 interface

• LD-BX-CH1 harness

• LD-BX-CH2 harness
