AXDI-GMLN10

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 10/30/23 INSTAXDI-GMLN10

Product Info

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket radio.

OPTIONAL ACCESSORIES (sold separately)

Extension Harness: AXEXH-GM10

TABLE OF CONTENTS

Connections: LD-LCLAN-10 Harness2 ......................

Installation3 .............................................................

Programming3 .........................................................

APPLICATIONS

INTERFACE COMPONENTS

• AXDI-GMLN10 interface • AXDI-GMLN10 harness

(1)(2) With RPO code I0B • With RPO code I0A

The , if applicable, are in the in the following locations:: Malibu IOA/IOB codesService Parts Identification labels Rear Compartment Floor

Glovebox: Note: RPO (QR codes)“B Pillar”VIN Canyon/Colorado/Cruze/Equinox/Silverado/Sierra are in the driver door jam or on the label.

GM Data Interface2016-2020

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

CHEVROLET

Colorado 2017-2019(1)........................

Cruze 2016-2019(2)..............................

Cruze Hatchback 2016-2019(2) ........

Equinox 2018(1)...................................

Malibu 2016-2019(2)............................

Silverado 2016-2018(1) .......................

Silverado LD 2019(1)...........................

Trax 2017-2020(2)...............................

GMC

Acadia 2017-2019(1) ....................

Canyon 2017-2019(1)...........................

Sierra 2016-2018(1)..............................

Sierra Limited 2019(1).........................

Visit for more detailed AxxessInterfaces.com

information about the product and up-to-date

vehicle specific applications.

INTERFACE FEATURES

• Used in non-amplified models, or when bypassing a factory amp

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

•

Provides illumination, parking brake, reverse, and speed sense

outputs

• Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Retains factory backup camera

• USB Micro-B updatable
