SPECIFICATION SHEET

ISPIRA - UCB3I SERIES

Under Cabinet

ISPIRA

HVI-2100 CERTIFIED RATINGS comply with new testing technologies

and procedures prescribed by the Home Ventilating Institute, for off-the-

shelf products, as they are available to consumers. Product performance

is rated at 0.1 in. static pressure, based on tests conducted in AMCA’s

state-of-the-art test laboratory. Sones are a measure of humanly-

perceived loudness, based on laboratory measurements.

Best| 926 West State Street, Hartford, WI 53027 | 1 800-558-1711 | www.BestRangeHoods.com

Best| 550 Lemire Blvd., Drummondville, QC Canada J2C 7W9 | 1 866-737-7770 | www.BestRangeHoods.ca

SIZE

STAINLESS

STEEL

BLACK GLASS

STAINLESS

STEEL

GREY GLASS

STAINLESS

STEEL

WHITE GLASS

STAINLESS

STEEL

WITHOUT

GLASS

BLACK

STAINLESS

STEEL

BLACK GLASS

GREASE

FILTERS

(replacement)

30-in. WideUCB3I30SBBUCB3I30SBSUCB3I30SBWUCB3I30SBNUCB3I30BLSB*62053

36-in. WideUCB3I36SBBUCB3I36SBSUCB3I36SBWUCB3I36SBN--62053

99046102B

FEATURES

Finish

430 Stainless Steel

or Black Stainless Steel* (available

only in Canada)

Cooktop Lighting2 LED Modules - 120 V, 5.5 W

Grease Filters

Hybrid Baffle, Stainless Steel with

Aluminum Mesh - Dishwasher Safe

OPTIONAL ACCESSORIES

Decorative Glass

Panels

Refer to Price List for options

MOUNTING HEIGHT

24-in. to 30-in. from cooktop to bottom of hood

LIMITED WARRANTY

5-year

(See installation manual for full warranty text.)

FOR INDOOR USE ONLY

PERFORMANCE

Damper/Duct

Connector

VoltsHzAmps

Discharge

Direction

SonesCFM

LowHighLowHigh

3¼-in. x 10-in.

(Included)

120601.8

Horizontal1.09.5160500‡

Vertical0.99.5160440‡

‡ If needed, ask a recommended installer to limit discharge to 300 CFM.

0.00

0.20

0.40

0.60

0.80

1.00

1.20

1.40

1.60

1.80

0100200300400500600

Static Pressure (in. w.g.)

Airflow (CFM)

HORIZONTAL

0.00

0.20

0.40

0.60

0.80

1.00

1.20

1.40

1.60

1.80

05010015020025030035040045050

0

Static Pressure (in. w.g.)

Airflow

(

CFM

)

VERTICAL

Dimensions shown in inches.

* Available only in Canada.
