will instantly shut off. To reset, simply place the
heater in an upright position and press the mode
button to reactivate the unit.
TRANSPORTING THE UNIT
Locate the pull down handle (C) above the control
panel. Pull down to release and then grasp the
handle. Pull the unit using the handle ensuring that
all castors are in contact with the floor.
NOTE: Do not use handle to lift the product .
STORAGE TIPS
If the heater is not required for long periods,
for example during the summer, it should be
stored at room temperature; in a dry place and
preferably covered to prevent the accumulation
of dust and dirt.
FITTING A REPLACEMENT PLUG FOR
U.K. AND IRELAND ONLY.
If the plug is not suitable for the socket outlets in
your home, it can be removed and replaced by
a plug of the correct type. For correct type and
correct installation please refer to “Installation of
a plug” below.
INSTALLATION OF A
PLUG – Applicable to
U.K. and Ireland.
NOTE: If you are in any
doubt about wiring and
the installation of the plug.
Please contact a qualified
electrician.
NOTE: If a 13A 3-pin
plug is fitted, it must be an ASTA approved
plug, conforming to the BS1363 standard.
Replacement 13 amp fuse must also be BSI or
ASTA approved.
The wires in this mains lead are coloured as such:
GREEN & YELLOW - Earth
BROWN - Live
BLUE - Neutral
Please note that the colour of these mains wires
may not correspond with the colour markings
that identify the terminals in your plug.
Please proceed as follows:
• The wire which is coloured GREEN & YELLOW
must be connected to the terminal which is
marked with the letter E (
) or is coloured
GREEN, or GREEN & YELLOW.
• The BROWN coloured wire must be connected
to the pin terminal, which is marked with the
letter L (Live) or is coloured RED.
• The BLUE coloured wire must be connected
to the pin terminal which is marked with the
letter N (Neutral) or is coloured BLACK.
• DO NOT CONNECT either of these wires
to the earth terminal in the plug. The earth
terminal is marked with the letter E (
) or is
coloured GREEN, or GREEN & YELLOW.
GUARANTEE
Please keep your receipt as this will be required for
any claims under this guarantee.
This appliance is guaranteed for 5 years after your
purchase as described in this document.
During this guaranteed period, if in the unlikely event
the appliance no longer functions due to a design or
manufacturing fault, please take it back to the place
of purchase, with your till receipt and a copy of this
guarantee.
The rights and benefits under this guarantee are
additional to your statutory rights, which are not
affected by this guarantee. Only Holmes Products
(Europe) Ltd. (“Holmes”) has the right to change
these terms.
Holmes undertakes within the guarantee period
to repair or replace the appliance, or any part of
appliance found to be not working properly free of
charge provided that:
• you promptly notify the place of purchase or
Holmes of the problem; and
• the appliance has not been altered in any way
or subjected to damage, misuse, abuse, repair
or alteration by a person other than a person
authorised by Holmes.
Faults that occur through, improper use, damage,
abuse, use with incorrect voltage, acts of nature,
events beyond the control of Holmes, repair
or alteration by a person other than a person
authorised by Holmes or failure to follow instructions
for use are not covered by this guarantee.
Additionally, normal wear and tear, including, but not
limited to, minor discoloration and scratches are not
covered by this guarantee.
The rights under this guarantee shall only apply
to the original purchaser and shall not extend to
commercial or communal use.
If your appliance includes a country-specific
guarantee or warranty insert please refer to the
terms and conditions of such guarantee or warranty
in place of this guarantee or contact your local
authorized dealer for more information.
This marking indicates that this product should
not be disposed with other household wastes and
should be disposed separately throughout the EU.
To prevent possible harm to the environment or
human health from uncontrolled
waste disposal due to the presence
of hazardous substances within
the product, recycle it responsibly
to promote the sustainable reuse
of materials and resources. To
return your used device, please use
the return and collection systems
available to you or contact the retailer
where the product was purchased. They can take
this product for environmentally safe recycling.
Holmes Products (Europe) Limited
1 Francis Grove
London
SW19 4DT
UK
4
Holmes Products (Europe) Ltd.
1 Francis Grove
London SW19 4DT
England
Fax: +44 (0)20 8947 8272
Email: enquiriesEurope@jardencs.com
UK - Filter Sales Order Line - 0870 759 9000
Website address: www.bionaire.com
UK - Free phone Customer Service Helpline – 0800 052 3615
© 2010 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved.
Distributed by Holmes Products (Europe) Ltd., 1 Francis Grove, London SW19 4DT, United Kingdom. Printed in PRC
© 2010 Sunbeam Products, Inc. faisant affaires sous le nom de Jarden Consumer Solutions. Tous droits réservés.
Distribué par Holmes Products (Europe) Ltd., 1 Francis Grove, London SW19 4DT, United Kingdom. Imprimé en RPC
P/N: 138197
INSTRUCTION MANUAL
OIL FILLED
RADIATOR
MODEL# BOH2503D
SPR-051010
pure indoor living
