Használati útmutató Bosch PGQ7B5K90
Olvassa el alább 📖 a magyar nyelvű használati útmutatót Bosch PGQ7B5K90 (12 oldal) a sütő kategóriában. Ezt az útmutatót 22 ember találta hasznosnak és 11.5 felhasználó értékelte átlagosan 4.9 csillagra
Oldal 1/12
Register your
new device on
MyBosch now and
get free benefits:
bosch-home.com/
welcome
Built-in gas hob
PGC6B.K9.. PGP6B.K9.. PGH6B.K9.. PGM7B.K9.. PGQ7B.K9..
[en]
Information for Use
2
PGC6B.K9..
CA B
F E
PGH6B.K9..
A
B
D F
D C
PGP6B.K9..
A
B
D
D
E
C
PGM7B.K9..
A
BC
D
D
EF
PGQ7B.K9..
A
BC
D
D
EF
1
Component
Pan support -
Control knob -
Economy burner 1.00 / 1.02kW
Standard-output burner 1.75 / 1.80kW
High-output burner 3.00 / 3.10kW
Mini-wok multi-crown burner 3.30 / 3.40kW
1
The images shown in these instructions are for guid-
ance only.
Safety en
3
Further information and explanations are available online:
Table of contents
1 Safety...................................................................3
2 Preventing material damage ..............................5
3 Environmental protection and saving en-
ergy ......................................................................6
4 Familiarising yourself with your appliance .......6
5 Accessories.........................................................7
6 Basic operation ...................................................7
7 Cookware.............................................................8
8 Recommended settings for cooking..................8
9 Cleaning and servicing.......................................9
10 Troubleshooting................................................10
11 Customer Service..............................................11
12 Disposal.............................................................11
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
The appliance can only be used safely if it is
correctly installed according to the safety in-
structions. The installer is responsible for en-
suring that the appliance works perfectly at its
installation location.
CAUTION‒Risk of injury!
This appliance is for cooking purposes only.
▶It shall not be used for other purposes, for
example room heating.
Only use this appliance:
¡To prepare meals and drinks.
¡Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡In a private household and in a domestic
environment.
¡Up to an altitude of 2000m above sea
level.
Do not use the appliance:
¡On boats or in vehicles.
¡as a room heater.
¡with an external timer or a remote control.
¡Outdoors.
Call the after-sales service if you want to con-
vert your appliance to a different type of gas.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of explosion!
Escaping gas may cause an explosion. WHAT
TO DO IF YOU SMELL GAS OR IF THERE
ARE FAULTS IN THE GAS INSTALLATION
▶Immediately shut off the gas supply or
close the gas cylinder valve.
▶Immediately extinguish all naked flames
and cigarettes.
▶Do not operate any light switches or appli-
ance switches.
▶Do not pull any plugs out of any sockets.
▶Do not use any telephones or mobile
phones within the building.
▶Open windows and ventilate the room.
Termékspecifikációk
| Márka: | Bosch |
| Kategória: | sütő |
| Modell: | PGQ7B5K90 |
