4K-HDR HDMI over Fiber USB KVM Extender
User Manual
BG-UHD-18GFE

Safety and Notice
The BG-UHD-18GFE 4K-HDR HDMI over Fiber USB KVM Extender has been tested for
conformance to safety regulations and requirements, and has been certified for international
use. However, like all electronic equipment, the BG-UHD-18GFE should be used with care.
Please read and follow the safety instructions to protect yourself from possible injury and to
minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is
on a stable surface.
● Use only the power adapter and power cords and connection cables designed for this
unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.
TABLE OF CONTENTS
INTRODUCTION ..................................................................................................................... 1
FEATURES ............................................................................................................................. 1
PACKAGE CONTENTS .......................................................................................................... 1
SPECIFICATIONS .................................................................................................................. 2
PANEL DESCRIPTIONS ........................................................................................................ 3
Transmitting unit .......................................................................................................... 3
Receiving unit .............................................................................................................. 4
CONNECTION DIAGRAM ...................................................................................................... 5
IR PASS-THROUGH ............................................................................................................... 6
HDMI PIN DEFINITION ........................................................................................................... 7
WARRANTY ............................................................................................................................ 8
SECOND YEAR ASSURANCE……..……..……..……..……..……..……..……..………….....9
MISSION STATEMENT……..……..……..……..……..……..……..……..……..……..………...9

1
INTRODUCTION
The BG-UHD-18GFE 4K-HDR HDMI over Fiber USB KVM Extender boosts up your video/audio
transmission distance up to 10km (6.25miles) over single mode fiber optic cables in Ultra-HD4K2K@60 format.
Users can readily extend Ultra-HD sources from DVD players, Blu-ray Disc player, PS4, PC, and any other
HDMI sources broadcasting to distant display monitors including HDMI or DVI enabled TV sets or LCD PC
monitors. Besides BG-UHD-18GFE is HDCP compliant, and supports IR& RS-232 pass-through path and
keyboard/mouse USB signal transmission.
FEATURES
● Supports 4K2K@60 4:4:4 8bits
● Supports HDR1, which is 4K2K@60 4:2:0 10bits2
● Supports HDCP2.2
● Extend HDMI signals up to 10km (6.25miles) over single mode fiber optic cables
● Supports Keyboard & mouse signal transmission
● Supports full frequency IR signal from 20KHz to 60KHz
● Bi-directional IR path-through
● Link LED indicator light
● Wall mounting housing design for easy and robust installation
PACKAGE CONTENTS
● 1x BG-UHD-18GFE [TX & RX]
● 1x IR blaster
● 1x IR receiver
● 2x DC 12V
● 1x User Manual
● 2x Single Mode Module [optional]
1. HDR = High Dynamic Range.
2. The video bandwidth of 4K2K@60 4:2:0 10bits (HDR) is 384 MHz, and the 4K2K@60 4:4:4
8bits is 594MHz.
The RS-232, IR and USB function cannot be used at the same time
