CE 22
Enhancer/Exciter & Surround Processor
Order ref: 170.938 UK
User Manual
Features
• Switchable Surround Processor
• Independent Bass Processors with 2 modes
• Variable Enhancer/Exciter process blend
• Balanced or unbalanced signal path
Version 1.1
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
2 170 38 User Manual .9 UK
Introduction:
Thank you for choosing this Citronic enhancer/exciter unit. This product has been designed deliver professional audio to
processing facilities with reliable and accurate function. In order to achieve the best results from this equipment and
avoid damage through misuse, please read and follow these instructions and retain for future reference.
Warning:
To prevent the risk of fire or electric shock, do not expose any part of the unit to rain or moisture.
If liquids are spilled on the surface, stop using immediately, allow unit to dry out and have checked by qualified
personnel before further use.
Avoid impact, extreme pressure or heavy vibration to the unit.
There are n user serviceable parts inside the enhancer/exciter fer all servicing to qualified service personnel. o –re
Safety
• Check that the supplied mains lead is in good condition and the supply voltage is correct.
• Ensure signal leads are of good condition and connected to appropriate inputs/outputs
• Do not allow any foreign particles to enter the unit through control apertures or connector apertures
Placement
• Keep out of direct sunlight and away from heat sources.
• Keep away from damp or dusty environments.
• When rack-mounting, avoid placing heavy units above the unit and ensure all connectors and contr are accessible ols
Cleaning
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a soft brush to clear debris from the control surface
• Do not use strong solvents for cleaning the unit.
3 170 38 User Manual .9 UK
Front Panel
Rear Panel
What is an Enhancer or Exciter
An Audio Enhancer is a multi-band processor which focuses selected high frequencies and applies specific filtering to
isolate and boost them without introducing other unwanted high frequencies, th us giving more “sparkle” and “liveliness”
to the signal.
An Audio Exciter is a processor which actively replaces missing high frequencies by actively generating overtones based
on the existing frequencies to introduce more dramatic and yet more synthetic, high frequency content.
The Bass Processor on each channel is a device which improves phase-alignment and focus of low frequencies, giving
similar attention to the bass as the Enhancer/Exciter does for the higher frequencies.
The SURROUND PROCESSOR vari phase-alignment between CH A and CH B to give the listener the impression that the es
sound is coming from increasingly different directions. This has the effect of a virtual widening of the stereo field when
CH A and CH B are used to process the left and ght channels of a mix. ri
Connection
The unit can be used in 2 configurations…
1. As 2 independent mono graphic enhancer/exciters e.g. for 2 separate microphone channel inserts –s on
2. As a stereo left & right processor e.g. as a main L+R enhancer/exciter on master inserts or between the mixer –
and amplifier or recording equipment
1. IN/OUT switch and LEDs: CH A
2. Bass Processor LOW MIX control: CH A
3. Bass Processor MODE switch: CH A
4. TUNE frequency control: CH A
5. PROCESS control of Enhancer/Exciter mix: CH A
6. HIGH MIX Enhancer/Exciter amount: CH A
7. SURROUND PROCESSOR IN/OUT switch & LED
8. SURROUND PROCESSOR amount
9. IN/OUT switch and LEDs: CH B
10. Bass Processor LOW MIX control: CH B
11. Bass Processor MODE switch: CH B
12. TUNE frequency control: CH B
13. PROCESS control of Enhancer/Exciter mix: CH B
14. HIGH MIX Enhancer/Exciter amount: CH B
15. POWER switch
21. Voltage Selector
22. IEC mains inlet & fuse
23. 6.3mm jack output: CH B
24. XLR output: CH B
25. 6.3mm jack input: CH B
16. XLR input: CH B
17. XLR output: CH A
18. 6.3mm jack output: CH A
19. XLR input: CH A
20. 6.3mm jack input: CH A
