Oldal 1/50
WARNING
• Read and understand product
labels and all instructions in
this manual and in your vehicle
owner’s manual before installing
or using this car seat.
• Failure to properly install or
use this car seat or follow these
warnings and those on this car
seat’s labels can result in serious
injury or death to the child
in a sharp turn, sudden stop
or crash.
C01-0602-C1-CA March2015
Foonf Instruction Manual
This car seat is designed for use either Rear-Facing or Forward-Facing by children who meet
all of the following requirements:
HEIGHT WEIGHT AGE
64 – 110 cm
25 – 43 in.
6.4 – 18 kg
14 – 40 lb
Able to sit
upright alone
HEIGHT WEIGHT AGE
76 – 124 cm
30 – 49 in.
10 – 29.5 kg
22 – 65 lb
2+ years
recommended
(1 year min)
0000 0031
ii
i
Checklist for Proper Use
IMPORTANT: This is only a checklist — you must read and understand all of the warnings and
instructions on this car seat’s labels and in this manual before installing or using this car seat.
When Using This Car Seat in Rear-Facing Mode
√ Child weighs between 6.4 and 18 kg (14 and 40 lb), height is between 64 and 110 c m (25
and 43 in.) and able to sit upright alone.
√ Car seat is securely installed in a vehicle rear seat using Rear-Facing Base and Anti-
Rebound Bar.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated and the vehicle owner’s manual states that this is an acceptable position to
install a Rear-Facing child restraint.
√ UAS lower anchor belt or vehicle belt is correctly routed under Seat Cushion in the Rear-
Facing belt path and there is no slack in the UAS lower anchor belt or the vehicle belt.
√ Car seat is reclined within an acceptable recline zone for the child’s age using a Rear-
Facing recline position.
√ The top of the child’s head is at least 2.5 cm (1 in.) below the top of the car seat Headrest.
√ Shoulder Harness Straps are through Shoulder Harness Slots closest to and at or below the
shoulder of the child.
√ Bottom of Headrest is at or above the Shoulder Harness Slots in use.
√ Crotch Strap is through Crotch Strap Slot at or behind and closest to the child’s crotch.
√ Harness is snugly adjusted on child and buckled.
When Using This Car Seat in Forward-Facing Mode
√ Child weighs between 10 and 29.5 kg (22 and 65 lb), height is between 76 to 124 cm
(30 and 49 in.) and is at least 1 year of age.
√ Car seat is securely installed in a vehicle rear seat without the Rear-Facing Base or the
Anti-Rebound Bar.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated, check the vehicle owner’s manual for proper use of a child restraint in
that position.
√ Car seat is correctly attached to the vehicle using either the rigid UAS lower connectors
and Top Tether; the vehicle belt and Top Tether; or the rigid
UAS lower connectors, the vehicle belt and the Top Tether.
– If child weighs more than 21.8 kg (48 lb) or the weight
limit specified for UAS use in your vehicle owner’s
manual, this car seat must be installed with the vehicle
belt and Top Tether.
√ Car seat is in a Forward-Facing recline position.
√ The top of the child’s ears are at or below the top of the
car seat Headrest.
√ Shoulder Harness Straps MUST be through Shoulder
Harness Slots closest to and at or above shoulders of child.
√ Bottom of Headrest is at or above the Shoulder Harness
Slots in use.
√ Harness Crotch Belt is through Crotch Belt Slot at or behind
and closest to the child’s crotch.
√ Harness is snugly adjusted on child and buckled.
For concerns related
to parts or the use and
maintenance of this
product, please contact
us at:
Clek Inc.
Attn: Customer Service
226 Lesmill Road
Toronto, ON
Canada
M3B 2T5
1-866-656-2462
www.clekinc.ca
1
2
Table of Contents
Checklist for Proper Use ....................................................................................... i
When Using This Car Seat in Rear-Facing Mode ............................................... i
When Using This Car Seat in Forward-Facing Mode .......................................... ii
Car Seat Features .............................................................................................. 3
Registration & Recall Information ......................................................................... 5
Registering Your Car Seat ............................................................................. 6
Warnings ......................................................................................................... 7
Certification ..................................................................................................... 11
Vehicle Classification ......................................................................................... 11
Size & Age Limitations ....................................................................................... 11
When Using This Car Seat in Rear-Facing Mode ............................................. 12
When Using This Car Seat in Forward-Facing Mode ....................................... 14
Vehicle Information ........................................................................................... 15
Vehicle Universal Anchorage System (UAS) .................................................... 15
Vehicle Seat Location Requirements .............................................................. 16
Vehicle Belt Requirements ........................................................................... 18
Vehicle Belt Systems ................................................................................... 19
Before Installing Car Seat .................................................................................. 22
Rear-Facing .............................................................................................. 22
Forward-Facing ......................................................................................... 23
Installing/Removing Rear-Facing Car Seat ............................................................ 23
Installing Rear-Facing Car Seat With UAS ..................................................... 25
Removing Rear-Facing Car Seat Installed With UAS ......................................... 31
Installing Rear-Facing Car Seat With Vehicle Belt ........................................... 33
Removing Rear-Facing Car Seat Installed With Vehicle Belt .............................. 40
Installing/Removing Forward-Facing Car Seat ....................................................... 41
Installing Forward-Facing Car Seat With UAS ................................................ 43
Removing Forward-Facing Car Seat Installed With UAS .................................. 53
Installing Forward-Facing Car Seat With Vehicle Belt ...................................... 55
Removing Forward-Facing Car Seat Installed With Vehicle Belt ........................ 60
Securing Your Child in Car Seat .......................................................................... 62
Removing Your Child From Car Seat ............................................................. 67
Operation and Adjustments ................................................................................. 68
Crotch Strap Adjustment ............................................................................... 68
Shoulder Harness Height Adjustment .............................................................. 70
Shoulder Harness Unthreading ............................................................... 71
Shoulder Harness Slot Adjustment ........................................................... 72
Shoulder Harness Rethreading ................................................................ 73
Shoulder Harness Cover Removal/Installation .................................................. 76
Installing/Removing Rear-Facing Base ............................................................ 77
Installing/Removing Rear-Facing Anti-Rebound Bar .......................................... 78
Removing/Installing Seat Cushion .................................................................. 81
Installing/Adjusting Headrest ........................................................................ 83
Rear-Facing UAS Storage ............................................................................. 85
Forward-Facing Rigid UAS Storage ................................................................ 87
Top Tether Storage ...................................................................................... 87
Instruction Manual Storage ........................................................................... 88
Removing/Installing Seat Cushion Cover ......................................................... 88
Aircraft Installation ............................................................................................ 90
Care and Cleaning ............................................................................................. 91
Troubleshooting ................................................................................................. 94
Accessories ....................................................................................................... 94
Warranty ......................................................................................................... 95
® Clek and Clek logos, Olli, Ozzi, Oobr, and Foonf are registered trademarks of Clek Inc.
For a complete list of Clek Inc. trademarks please visit www.clekinc.ca/trademarks.
