How to Install

1. Decide the preferred hanging height and

choose the correct length of rods needed.

2. Feed the wires and safety cable through the

rods,screw collar loop and canopy.Screw the

rods together. Screw one end of the rod

assembly onto the top of frame and the other

end onto the swivel on the mounting strap.

3. Place the mounting strap over the outlet box

and mark two points on the ceiling with

same distance as between the two holes on

the mountng strap. i

4. Drill the holes at the marked points and insert

the plastic anchors into the holes.

5. Raise the fixture up to the ceiling and wrap the

safety cable around the mounting strap and

secure with the locking device.When the wire

connections are made, slip the canopy up

along the rods and over the mounting strap.

Secure with the screw collar ring.

6. Install the bulb into the socket.

7. Dress the glass as illustrated.

Glass Sets

1.6 pcs glass 2 3/4x7 3/4”1White

Crystorama.com

ADD-312--AGWH

1

5

3

2

4

Ø140 [5

1

2

"]

25 [1"]

6

RODS (3-12")

ROD (1-6")

Ø19 [

3

4

"]

Ø677 [Ø26

5

8

"]

543 [213

8"]

61PCS

Tier#1

Tier#2

Tier#3

Tier#4

Tier#5

Tier#6

Tier#7

Dress the glass from tier #7.

1612 [631

2"]

You will need 12 Candelabra Base Bulb

40 Watts Recommended 60 Watts Max.

USE LED BULBS FOR EXTENDED USE

( This fixture is ry rated)d
