PIL-M01

Cubic personal interlock

Entrance systems

Subject to change without notice

Standard unitsPIL-M01

Construction

Upper section length31-1/2"–78-3/4" (800 mm–2000 mm)

Passage width31-1/2"–47-1/4" (800 mm–1200 mm)

Outer dimensionDependant on sizes and configurations

Total height98-7/16” (2500 mm)

Passage height89-3/8” (2270 mm)

Upper part of body9-1/16" (230 mm)

Body

Outer doorOptional (swing door, folding wing, sliding door, fire

rated door) or retrofit over existing swing door.

Inner doorOptional (swing door, folding wing, sliding door, fire

rated door) or retrofit over existing swing door.

FinishAnodized aluminum, powder coated, and stainless steel.

FunctionDefault position inside and outside locked.

Initial swing door is opened by a motor-driven system

(or manual) in the direction of entry or exit by a floating

release signal. The door closes and locks automatically

after entrance to the interlock. Upon validation, the

second door releases. Upon exiting, the personal

interlock closes and locks.

PIL Vision anti-piggybacking

Interior biometrics.

Lighting can be installed.

Electrical equipmentNetwork-compatible ETS 22 CAN bus control unit

integrated in the unit.

InstallationWith side walls on finished floor level FFL.

The ambient conditions must be checked for

outdoor installation.
