Oldal 1/12
1
Be sure to read this installation manual thoroughly prior to installation and making connections. If installation
methods or non-standard parts not specified in this installation manual are used, accidents or injury may
result.
Professional techniques and experience are required in order to install this system. It is recommended that
you contact the place of purchase for installation to be carried out. After reading the installation manual
thoroughly, keep them in a safe place for later reference.
To dealers:
Give this installation manual to the customer after installation and all connections have been completed.
REAR CAMERA
INSTALLATION MANUAL
Components
Installation Diagram
For your safety in using the BEC105
Installing the Rear Camera
Camera Angle Adjustment
2
2
Points to note after installing the rear camera
4
6
11
Before
installation
Installation
System Connection Example
12
Connections
Contents
Contents
5
MODEL
3-28510BEC105A5版(英語)05.8.236:46PMページ1
