Oldal 1/26
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate
Owner’s Manual
Please read this manual carefully before
operating your set.
Retain it for future reference.
Record model number and serial number
of the set.
See the label attached on the set and
quote this information to your dealer
when you require service.
DISHWASHER
MODEL: EDW-B1461(WH)
REMOVE ALL PACKING MATERIALS FROM THIS PRODUCT BEFORE USING IT. THIS
APPLIANCE MUST BE INSTALLED IN LEVEL. PLEASE ENSURE THE ELECTRICITY
SUPPLY TO THIS APPLIANCE IS DISCONNECTED BEFORE INSTALLING.
Please read this instruction carefully. It is advisable to keep this instruction manual in a
safe place for future reference.
SAFETY PRECAUTIONS
1. Keep this appliance out of reach from children. Do not let them to operate the
appliance without supervision.
2. Check the current rating on the rating plate and make sure the current supplied is
matched with the appliance before using.
3. This product is for household and indoor use only.
4. This product is not intended for use by person (including children) with reduced
physical, sensory or mental capabilities unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
5. If the power cord or plug is damaged, it must be replaced by the service centre or a
qualified service technician to avoid hazard.
6. Any electrical work required to install this appliance should be carried out by a qualified
technician or competent personnel.
WARNING - to reduce the risk of fire or injury to persons or property, please
read and follow below instructions carefully:
• Do not operate this appliance if it has malfunctioned, damaged or appears damaged in
any way. Make enquiry to our service centre and return the complete set to the place of
purchase for inspection, repair or replacement.
• This appliance must be grounded and the ground wire should not be connected to any
heating pipe and gas pipe.
• The plug must be plugged into an appropriate outlet that is installed and grounded in
accordance with all local codes and ordinances.
• Do not abuse, sit or stand on the door or dish rack of the unit.
• Do not operate the appliance unless all enclosure panels are properly in place. Open
the door carefully if the appliance is operating, there will be risk of water squirting out.
• Do not place heavy objects or stand on the appliance door when it is open.
With each wash cycle.
Compartment
For pro gramm es with pre-wash only.
(Follow the user instructions !)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models w ith water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Close the door, t urn on the water tap and press the . The machine will start working
after about 10 seconds.
Start/Pause Button
Running the dishwasher
Switch off the applia nce
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 min utes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then l oad the baskets. Refer to the dishwasher loading instr uct ions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operationg instruction )“ ”
When the working cy cle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the On/Off Button.
If the appliance is switched
off during a wash cycle.
Op en t he do o r car e f ull y.
Hot st eam may escape
when the door is opened!
If the appliance is switched off during a wash cycle, when switched
on agai n, plea se re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press t he On/Off button to switch on the applian c e, Open the door.
For detailed operating method read the corresponding content on the instruction manual.
1. A running cycle can o nly be modified if it has been running fo r a short time. O therwise the detergent
m ay have alre ady be en released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Pres s the Start/ Pause button then press the program button for more than 3 seconds to cancel the
running programme.
3. Select a new programme.
4. Restart the dishwash er.
1.Press the Start/Pause button to stop the machine.
2.Open the door.
3.Add the forgotten di shes.
4.Close the door, then press the Start/ Pause bu tton, the dishwasher will
start running again after 10 seconds.
