060817-DR www.elitescreens.com 1

Manual Pull-Down Projection Screen

Elite Manual Series

USER’S GUIDE

Pre-installation

1. Carefully unpack the screen.

2. Always handle the screenin a leveled position on a clean surface.

INSTALLATION

Flush Wall Mounting

1.Measure the distance between the keyholes located on the back of the end cap

2.Mark the location of where the screen is to be installed for the pre-drilled hole.

3.After marking the area and drilling the hole, insert the proper screw into the drilled hole and leave

about 1/8” of an inch from the wall to mount the screen.

4.Mount your screen from the keyhole located on back of screen’s left and right end cap.

Back of end cap

Front view

Side view
