Translation of the original instructions

1Further applicable documents

All available documents for the product www.festo.com/pk.è

Observe further applicable documents:

–Instruction manual for drive

2Safety

2.1Safety instructions

–Only assemble the product on components that are in a condition to be safely

operated.

–Observe tightening torques. Unless otherwise specified, the tolerance

is±20%.

2.2Intended use

Fasten the drive to the base profile by the dove-rail connection.4

3Further information

The dimensions of the MUC and other fastening fittings

èwww.festo.com/catalogue.

4Product range overview

4.1Included in delivery

1

Plate (1x)

2

Clip (1x/2x)

3

Screw (2x)

Fig. 1 Profile mounting

4.2Not included in the delivery

4

Drive (1x) e.g. DGC, DGC-FA, DGCI

Fig. 2 Actuator

5

Screw (2x)

Fig. 3 Screw

•Screws select screws suitable for the installation situation.5

MUC-...8/121825/324050/63

5ScrewM3M5M5M6M7

Tab. 1 Screw size

5Assembly

Mounting variant 1Mounting variant 2

Tab. 2 Assembly variants

•Select mounting variant.

Fig. 4 Determine support spacing

1.Determine support spacing L 1 Further applicable documents.è

2.Position plate on the support points.1

Fig. 5 Attach plate

•Fasten plate to mounting surface with screws.15

Fig. 6 Fixing drive

1.Position drive with the dove-tail profile(A) on the plate.41

2.Fasten clip with the screws to the dove-tail profile(A).23

Ä

The drive can still be moved.4

Fig. 7 Fastening drive

1.Position drive.4

2.Tighten screws evenly and symmetrically. 3

MUC-...8/121825/324050/63

ScrewM3x8M4x12M5x12M6x16M8x25

Strength8.810.9

3

[Nm]1.24.18.31420

Tab. 3 Tightening torque

8048068

MUC

Profile mounting

8048068

2018-06

[8065945]

Instructions| Assembly

Festo SE & Co. KG

Ruiter Straße 82

73734 Esslingen

Germany

+49 711 347-0

www.festo.com
