Használati útmutató Full Boar FBT-0500U
Olvassa el alább 📖 a magyar nyelvű használati útmutatót Full Boar FBT-0500U (9 oldal) a Hamer kategóriában. Ezt az útmutatót 14 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra
Oldal 1/9
WARNING: Read all safety warnings and instructions before use. Failure
to follow the warnings and instructions may result in electric shock, fire and/or
serious injury. Save these warnings and instructions for future reference.
02/17
ROTARY HAMMER
DRILL KIT
• 5 JOULES
• 1250W POWER
INSTRUCTION MANUAL
2
Voltage: 230V ~ 50Hz
Power: 1250W
Impact Power: 5 Joules
Impact Rate: 0-4,100/min
No Load Speed: 0-850/min
Accessory Fitment: SDS-Plus
Drilling Capacity: 32mm
Weight: 7.9kg
SPECIFICATIONS - MODEL NO. FBT-0500U
KNOW YOUR PRODUCT
1. SDS-plus accessory holder
2. Accessory locking sleeve
3. Depth rod locking dial
4. Side mode selector
5. Grease cap
6. Rear mode selector
7. On/off trigger
8. Pressure indicator light
9. Soft grip rear handle
10. Service indicator LED
11. Side handle
12. 250mm x 24mm flat chisel bit
13. Depth rod
14. Dust cover
1
2345
6
7
9
10
1112
8
14
13
4
Congratulations on purchasing a Full Boar rotary hammer kit.
It has been designed to rapidly drill, chip, chisel and break
masonry products such as concrete.
Read and understand the instruction manual before operating
the demolition hammer. Failure to do so could result in
personal injury or equipment damage.
INTRODUCTION
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read the whole manual carefully, and make sure you know how to switch the tool off in an emergency,
before operating the tool. Save these instructions and other documents supplied with this tool for
future reference. The manufacturer cannot accept any liability for damage or accidents which arise
due to a failure to follow these instructions and the safety information.
Before you connect the equipment to the mains supply make sure that the data on the rating plate is
identical to the mains data.
This tool is double insulated therefore no earth wire is required.
The power supply for this product should be protected by a residual current device (rated at 30mA or
less). A residual current device reduces the risk of electric shock.
If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord
available through the service organisation.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool. The insulation system is for added protection against injury resulting from a possible electrical
insulation failure within the tool.
Using an extension lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or
defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead
not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire
and electric shock.
ELECTRICAL SAFETY
Termékspecifikációk
| Márka: | Full Boar |
| Kategória: | Hamer |
| Modell: | FBT-0500U |
