SDM630MCT V2 is a multi-functional din-rail meter designed for accurate measurement and display of parameters in 3P3W/3P4W power

grid systems, such as voltage, current, power, frequency, active power, reactive power, positive energy, reverse energy, total harmonics,

etc. It is an ideal choice for real-time power monitoring, featuring a wide range of functions and applications with high stability over

extended service life. The meter works with an external current transformer and can be applied in both high and low voltage power grid. It

comes with an RS485 communication interface, which supports a maximum baud rate of 38400 bps and enables remote communication.

TPM-CT-E-EU(SDM630MCT V2) Three-phase

Smart Meter Quick Guide

General Specifications

Rated voltage

3×230/400Vac

Rated frequency

50/60Hz

L-N voltage range

100 ~ 276Vac

L-L voltage range

173 ~ 480Vac

Auxiliary power voltage range

85 ~ 275Vac or 120 ~ 380Vdc

AC withstand voltage

4KV for 1min

Input current range

1A or 5A

Short-term overcurrent

20*IMAX for 0.5s

Max. Reading

9999999.9kWh/kVArh

Accuracy

Active power

0.5% of range maximum

Reactive power

0.5% of range maximum

Environment

Regulated working temperature

range

-℃～+℃2555

Limited working temperature range

-℃～℃40+70

Relative humidity annual average

≤90％

Installation category

CAT III

Degree of pollution

RoHS compliant

Communication

Communication

RS485 output for Modbus RTU

Baud rate

9600bps(default)

Pulse

3200imp/kWh

Mechanics

Outline dimensions

94.5x72x65mm(LxWxH )

Din rail dimensions

DIN rail 35mm

Protection level

IP51 (indoor)

Item

Quantity

Description

A

1

Three-phase meter

B

1

Quick Installation Guide

C

1

RS485 cable (standard length: 15m)

D

3

Current Transformer

1

1

1

11.

.

.

..

Overview

2

2

2

22.

.

.

..

Technical Parameters

3

3

3

33.

.

.

..

Unpacking

Quick

installation

man

ual

ABCD

4

4

4

44.

.

.

..

Dimensions (Unit: mm)

5

5

5

55.

.

.

..

Installation

1. The Growatt Storage Inverter and the Hybrid Inverter are hereinafter referred to as "the Storage/Hybrid Inverter".

2. The grid is on the right side and the current flows from P1 to P2 (from the grid to the load).

Note:

Storage/

Hybrid

Inverter

Grid

L1

L2

L3

N

1

23

4

5

6

7

8

910

11

12

13

14

15

16

17

1819

20

L

N

L

N

Voltage inputs

So

Current inputs

RS485

RS485-A

RS485-B

S2S1

S2

S1

3P3W

PE

1

23

4

5

6

7

8

910

11

12

13

14

15

16

17

1819

20

L

N

L

N

Voltage inputs

So

Current inputs

RS485

RS485-A

RS485-B

S2

S1

S2

S1

S2

S1

3P4W

PE

P2

P1

35mm

35mm

94.5mm

72mm

65mm

P2

P1

Storage/

Hybrid

Inverter
