Oldal 1/13
Type 07
Operation Manual
EN DE
Heinz Electrodynamic Designs
EN
Heinz Electrodynamic Designs
Safety Instructions
Please read the following safety instructions carefully before setting up your system. Keep the instructions for subse-
quent reference. Please read the warnings and follow the instructions.
To reduce the risk of an electric shock, do not open the loudspeaker yourself. Always refer to qualified service personnel.
This product must be connected with an IEC 60320 AC mains power cord (like the one we supplied).
Please switch o your audio system before connecting or disconnecting any cables to the speaker – also, if you intent to
clean the surface or single components. Never use flammable or combustible chemicals for cleaning audio components.
HEDD studio monitors are equipped with universal mains, meaning that the speakers work within a voltage range from
85–264V. This makes voltage switches unnecessary.
Do not place this unit on an unstable cart, stand or tripod, bracket or table. The unit may fall, causing serious injury and/or
serious damage.
This product should never be used outside. Avoid exposing it to rain or any sort of moisture.
Powercords and audio cables connected to this product should never be stepped on.
Please note that defective cables can harm your speakers and / or create humming, crackling, etc.
Always keep electric equipment out of the reach of children.
Always unplug sensitive electronic equipment during lightning storms.
The monitor should be installed near the socket outlet and quick disconnection of the device should be easily possible.
To completely disconnect the speaker from the AC mains, physically disconnect the powerchord.
Please try to avoid touching the speaker diaphragms. Always keep the woofer’s ventilation ports open.
Don't use the speaker at very high or low temperatures. The speakers back panel should not be exposed to direct sunlight.
Never operate this product in an explosive atmosphere.
High SPL’s can irreparably damage your ears! Please take good care when running the speakers at high levels.
Make sure that the air can circulate behind the speaker as it needs sucient cooling.
Only mount this product onto dry and non-conducting walls (wood, plaster). For other wall materials, an additional isolation
panel is required. To prevent injury, this loudspeaker must be securely attached to the wall in accordance with the installation
instructions of your wall mount bracket
Always carry the speaker with the back panel facing to your body. Otherwise, the diaphragm of the woofer can be damaged,
which is not covered by the warranty.
The drivers of the speaker are NOT magnetically shielded! Keep away all items that are sensitive to magnetic fields, like mag-
netic tapes, credit cards, CRT monitors and so on.
Keep away Ferro-magnetic (steel, iron, etc.) objects from the tweeter like small screws, swarf and so on. The strong magne-
tic field of the tweeter can pull objects to the folded diaphragm. This can lead to permanent damage of the tweeter, which is
not covered by the warranty.
For cleaning the surface of the cabinet, we recommend to use a microfiber cloth and simply warm water. Don’t use any
aggressive detergent, as it will damage the finish. Always switch o the speaker before cleaning! For cleaning dust out of the
loudspeaker diaphragms, use a very soft brush.
If you need to send the speakers via a postal service, use the original packaging. It is the safest way to get them from A to B.
ExplaNatioN of Graphical SymbolS
CAUTION
RISK OF ELECTRIC SHOCK!
DO NOT OPEN!
CAUTION
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT REMOVE THE BACK COVER OR ANY OTHER PART. NO
USER-SERVICEABLE PARTS INSIDE.
DO NOT EXPOSE THOS EQUIPMENT TO RAIN OR MOISTU-
RE. REFER SERVICING TO QUALIFIED PERSONNEL.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous volta-
ge” within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
EN
Heinz Electrodynamic Designs
HI THERE,
and first of all: Many thanks for choosing our Type 07
nearfield studio monitor. We are stoked to have you on
board as a customer. Without any more hestitation we
would like to take you through the basics of this powerful
and ultra-transparent active loudspeaker, that is suitable
for all kinds of audio-related jobs, may it be mixing in ste-
reo or multichannel setups, mastering, producing beats,
recording string quartets, rockbands, or anything that is
related, really …
Let’s assume that you unpacked the monitor carefully and
that you gave a little bit of time to acclimate to the tem-
perature of your room (an hour is safe). Let’s also assume
that you couldn’t wait to connect it to the power socket
(8) and your audio system using the balanced XLR, unbal-
anced RCA, or HEDD Bridge inputs (1, 6, 7).
Now is the time to confirm the input you used by select-
ing it on the SOURCE Switch (5) – and to finally press that
power switch on the back panel. There you go!
Note: By the way, do you know that these speakers are
equipped with regulated Universal Mains, working from
85V-264V (8)? This means that our amps will work at their
full capacity under any voltage condition. Just saying …
GAIN
Now, there is a lot you can tweak on the back panel to
adapt the speaker to your working environment. First
of all, you have a proper GAIN-Control (4) that lets you
adjust the overall volume of the speaker in a range from
-30dB to +6dB. You can use this control to adapt the
speakers to your signal chain and to compensate for any
level dierences between the speakers, may they be
caused by your listening position, the room acoustics, or
slight variations of the control knob’s tolerance (which is
normal and no malfunction).
SHELVING FILTERS FOR ROOM ADJUSTMENTS
Listening to these monitors can be a real joy, but depend-
ing on your room and its acoustical properties, you might
not really feel it. Your room might be very small so that
the speakers are close to a wall or corner (hello, bass-
boost!). You might have to work in a super-bright and big
room with hard surfaces such as glass or stone, or the
other way around, in a particularily mued sounding room
with big curtains and beautiful but thick carpets.
In situations like these, it is dicult to impossible for the
speaker to unfold its rich sound quality. That’s why we
designed two very eective shelving-filters (2, 3). Here is
how they work:
• the Low Shelf lets you reshape the bottom end
around 50Hz (± 4dB)
• the High Shelf helps you to bring back the details
and transparency around 20kHz (± 4dB)
Introduction
1
8
EN
Heinz Electrodynamic Designs
7
2
3
4
5
6
