Installation Guide
Included Installation Instructions
Network Camera
Model No. WV-S61501-Z1
WV-S61301-Z2
WV-S61301-Z1
WV-U61301-Z2
WV-U61301-Z1
About the user manuals
Product documentation is composed of the following documents.
• Provides information about “Precautions”, Installation Guide (this document):
“Precautions for installation” and the installation method.
• Basic Information (Refer to the link on the following product information website): Provides
information about “Precautions for use”, “Parts and functions” and “Detail specifications”.
• Operating Instructions (Refer to the link on the following product information website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
“<Control No.: C****>” used in these documents should be used to search for information on
our technical information website (https://i-pro.com/global/en/surveillance/training-support/
support/technical-information) and will guide you to the right information.
• Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
• microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
• The external appearance and other parts shown in this manual may differ from the actual product within the
scope that will not interfere with normal use due to improvement of the product.
Indoor use
For professional use only
NOTE: This equipment has been tested and found
to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment gener-
ates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
FCC CAUTION: Changes or modifications not
expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the
equipment.
Supplier’s Declaration of conformity
Trade name : i-PRO
Model No. : WV-S61501-Z1
WV-S61301-Z2/ WV-S61301-Z1
WV-U61301-Z2/ WV-U61301-Z1
Responsible Party :
i-PRO Americas Inc.
8550 Fallbrook Drive, Suite 200 Houston,
Texas 77064
Support Contact : 1-800-513-5417
For U.S.A.
CAN ICES-3(A)/NMB-3(A)
For Canada
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
For U.S.A.
The model number and serial number of this prod-
uct may be found on the surface of the unit.
You should note the model number and serial num-
ber of this unit in the space provided and retain this
book as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
For U.S.A.
Méthode d’installation Vis de fixation recommandée La capacité de traction minimale requise
Quand la caméra vidéo est directement
installée au plafond ou sur le mur.
M4 or M6 x 16 mm {5/8 pouces}
/ 4 él.
196 N {44 lbf}
* La longueur de la vis est un exemple lors de l’installation de la caméra au plafond ou sur un mur robuste d’une
épaisseur de 20 mm {25/32 pouces} ou plus.
Disposal of Old Equipment and Batteries
Only for European Union and countries with recycling systems
These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any potential
negative effects on human health and the environment.
For more information about collection and recycling, please contact your local authority.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
Note for the battery symbol (bottom symbol)
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.
Precautions 2 ........................................................
Open source software 3 ........................................
Copyright 3 ...........................................................
Trademarks and registered trademarks 3 ...............
Precautions for installation 3 ..................................
Troubleshooting 3 ..................................................
Specifications. 4 ....................................................
Optional accessories 4 ..........................................
Standard accessories 4 .........................................
Other items that are needed (not included) 4 .........
Installation Procedure 5 .........................................
Contents
© i-PRO Co., Ltd. 2022
N0422-2122
PGQP3606XA
WV-S61301-Z2
Tokyo, Japan
https://www.i-pro.com/
Authorised Representative in EU:
i-PRO EMEA B.V.
Laarderhoogtweg 25, 1101 EB
Amsterdam, Netherlands
i-PRO EMEA B.V. UK Branch
1010 Cambourne Business Park,
Cambridgeshire CB23 6DP
2
Precautions
■ Do not insert any foreign objects.
Fire or electrical shock may be caused if water or any foreign objects, such as metal objects, enter inside the unit.
Turn the power off immediately and contact qualified service personnel for service.
■ Do not use this product in an inflammable atmosphere.
Failure to observe this may cause an explosion resulting in injury.
■ Avoid installing this product in the locations where salt damage occurs or corrosive gas
is produced.
Otherwise, the mounting portions will deteriorate and injury or accidents due to a fall of the product may occur.
■ Do not strike or give a strong shock to this product.
Failure to observe this may cause injury or fire.
■ Keep microSD memory cards away from infants and children.
Otherwise, they may swallow the cards by mistake.
In this case, consult a doctor immediately.
■ Do not hang down from this product or use this product as a pedestal.
Failure to observe this may cause injury or accidents.
■ Do not damage the power cable.
Do not damage, fabricate, twist, stretch, bundle, or forcibly bend the power cable.
Do not place heavy objects on it, and keep it away from heat sources.
Use of a damaged power cable may cause electric shock, short circuit, or fire.
Consult the dealer for repair.
■ Do not use the screw hole for the camera screw for installation on a ceiling.
Failure to observe this may cause a drop resulting in injury or accidents.
Use the provided camera mount bracket for installation.
■ Do not touch the camera while this product is panning/tilting.
Fingers may be caught up in the moving part, and that may result in injury.
■ Do not install this product in an unstable location (for desktop use)
Selecting an inappropriate installation surface may cause the product to fall down or topple over, resulting in
injury or accident.
WARNING:
• Operation of this product in a residential environment could cause radio interference.
Caution:
• The DC power supply connected to the camera
must be in the same building.
• The network camera is only intended for a connection
to an ethernet or PoE network without routing to the
outside plant.
• This product has no power switch. Be sure to install
disconnect devices such as a circuit breaker to shut
down the main power of power supplying equipment
to this product.
• Only connect 12 V DC Class 2 power supply (UL 1310/
CSA 223), limited power source (IEC/EN/UL/CSA
60950-1, IEC/EN/UL/CSA 62368-1 Annex Q) or IEC/
EN/UL/CSA 62368-1 PS2.
• Before attempting to connect or operate this product,
please read these instructions carefully.
Notice:
• This product is not suitable for use in locations
where children are likely to be present.
• Do not install this product in locations where
ordinary persons can easily reach.
• This product is a professional equipment.
• For information about screws and other parts
required for installation, refer to the correspond-
ing section of this document.
: Direct current symbol
■ Do not attempt to disassemble or modify this product.
Doing so can cause fire, electric shock, etc.
Ask your dealer for repair and inspection.
■ Do not install or clean the camera, or touch this product, the power cable or the
connected cables during thunder storms.
Failure to observe this may cause electric shock.
■ Refer installation work to the dealer.
Installation work requires technique and experience.
Failure to observe this may cause fire, electric shock, injury, or damage to the product.
Be sure to consult the dealer.
■ Stop the operation immediately when something is wrong with this product.
When smoke goes up from the product, the smell of smoke comes from the product, or the exterior of the product
has deteriorated, continued use will cause a fire or fall of the product resulting in injury, or damage to the
property.
In this case, turn the power off immediately and contact qualified service personnel for service.
■ Select an installation area that can support the total weight.
Selecting an inappropriate installation surface may cause the product to fall down or topple over, resulting in
injury or accident. Installation work shall be started after sufficient reinforcement.
■ Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause a fall of the product resulting in injury or accidents.
Consult the dealer for the inspections.
■ The exclusively designed mount bracket shall be used. (except for desktop use).
Failure to observe this may cause a drop resulting in injury or accidents.
Use the exclusively designed mount bracket for installation.
■ The screws and bolts must be tightened to the specified torque.
Failure to observe this may cause a drop resulting in injury or accidents.
■ Turn the power off when do wiring of this product.
Failure to observe this may cause electric shock.
In addition, short circuit or wrong wiring may cause fire.
■ Install this product in a location high enough to avoid people and objects from bumping
the product.
Failure to observe this may cause injury.
■ Do not install this product in locations subject to vibration.
Loosening of mounting screws or bolts may cause a fall of the product resulting in injury or accidents.
■ Correctly perform all wiring.
Short circuits in the wiring or incorrect wiring may cause fire or electrical shock.
■ Install the product securely on an installation surface in accordance with the installation
instructions.
Failure to observe this may cause injury or accidents.
■ Do not rub the edges of metal parts with your hand.
Failure to observe this may cause injury.
■ Do not touch the metal part of the bottom side of the product.
The metal part of the bottom side may become hot while the product is in use. Direct skin contact with high
temperature parts of the product may cause burns.
■ Turn the power off when cleaning this product.
Failure to observe this may cause injury.
3
Open source software
• This product contains open source software licensed under GPL (GNU General Public License), LGPL (GNU
Lesser General Public License), etc.
• Customers can duplicate, distribute and modify the source code of the software under license of GPL and/or
LGPL.
• For details concerning licensing and source code of open source software, click “Click here for OSS informa-
tion” on “Support” page of the setup menu of this product and read the displayed content.
• Please note that we shall not respond to any inquiries regarding the contents of the source code.
Copyright
Except for open source software licensed under GPL/LGPL and so on, distributing, copying, disassembling,
reverse compiling and reverse engineering of the software provided with this product are all expressly prohibited.
In addition, exporting any software provided with this product violating export laws is prohibited.
Trademarks and registered trademarks
• Microsoft, Windows, Windows Media, Microsoft Edge, and ActiveX are either registered trademarks or trade-
marks of Microsoft Corporation in the United States and/or other countries.
• Intel and Intel Core are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
• Adobe, Acrobat, and Reader are either registered trademarks or trademarks of Adobe in the United States
and/or other countries.
• microSDXC Logo is a trademark of SD-3C, LLC.
• iPad and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
• Android and Google Chrome are trademark of Google LLC.
• Firefox is a trademark of the Mozilla Foundation in the US and other countries.
• The word “QR Code” is a registered trademark of DENSO WAVE INCORPORATED in Japan and other countries.
• All other trademarks identified herein are the property of their respective owners.
Precautions for installation
i-PRO Co., Ltd. assumes no responsibility for injuries or property damage resulting from failures
arising out of improper installation or operation inconsistent with this documentation.
■ In order to prevent injury, the product must be securely mounted to an installation
surface according to Installation Guide.
■ Installation area for this product
Select an appropriate place for the installation area (such as a strong installation surface) in your particular environment.
• Make sure that the installation area is strong enough to hold this product, such as a concrete ceiling.
• Install the camera in the foundation area of the architecture or where sufficient strength is assured.
• Do not mount the product on a plaster board or a wooden section because they are too weak. If the product
is unavoidably mounted on such a section, the section shall be sufficiently reinforced.
• Do not use the screw hole for the camera screw for installation on a ceiling.
■ This camera is designed to be used indoors.
• This product is not operable outdoors. Do not expose this product to direct sunlight for hours and do not
install the product near a heater or an air conditioner. Otherwise, it may cause deformation, discoloration and
malfunction. Keep this product away from water and moisture.
■ Do not place this product in the following places:
• Locations where a chemical agent is used such as a swimming pool
• Locations subject to moisture or oil smoke such as a kitchen
• Locations that have a specific environment that is subject to an inflammable atmosphere or solvents
• Locations where a radiation, an X-ray, a strong radio wave or a strong magnetic field is generated
• Locations near coasts directly subjected to sea breezes, or locations subject to corrosive gases such as from
hot springs, volcanic regions, etc.
• Locations where the temperature is not within the specified range
• Locations subject to vibrations, such as on vehicles, marine vessels, or above product lines (This product is
not designed for on-vehicle use.)
• Locations where it may get directly wet from rain or water splash (including under the eaves, etc.)
• Locations subject to moisture or dust
• Locations subject to sudden changes in temperature such as near air discharge vents of air conditioners or air
circulation inlet doors
• Locations near rubber products containing sulfur (packing, rubber feet, etc.)
■ Screw tightening
Do not use an impact driver. Use of an impact driver may damage the screws or cause tightening excessively.
■ About reflection of light from outside
A ghost may appear on the screen depending on the incident angle of external light.
• Refer to our technical information website <Control No.: C0109> for image examples and measures to take.
■ Take notice of humidity.
Install this product when the humidity is low. If installation is performed when it is raining or in very humid condi-
tions, the inside may be affected by humidity, causing mist-over inside the dome cover.
■ Protection against lightning
When the cables brought from outdoors are used, there is a chance that they may be affected by lightning.
In such a case, install a lightning arrestor close to the camera, and make the length of the network cable
between the camera and lightning arrestor as short as possible to prevent the camera from being affected by
lightning.
■ When noise disturbance may happen
Noise may appear in video or audio near a strong electric field from a TV or radio antenna, motors and trans-
formers, or a strong electric field/magnetic field from a power line (lamp line) of AC 100 V or more. Conduct the
power distribution work to keep 1 m {3.28 feet} away from them or conduct the electric conduit work using
metal pipes. (Be sure to make ground connection of the metal pipes.)
■ Make sure to remove this product if it will no longer be used.
■ This product has no power switch.
When turning off the power, disconnect the power supply from the 12 V DC power supply or the PoE device.
■ About the battery
A battery is installed inside the camera. Do not leave the battery exposed in environments of excessive heat as a
result of sunlight or fire.
■ Equipment classification and power source indication label
Refer to the indication label on the bottom side of this unit for the equipment classification, power source, and
other information.
■ About static electricity
Before installing or removing this product, be sure to touch metal objects to discharge static electricity from your
body.
Troubleshooting
Before requesting service, refer to “Troubleshooting” of “Basic Information” and “Operating Instructions”. Then,
confirm the trouble.
Termékspecifikációk
| Márka: | I-PRO |
| Kategória: | Térfigyelő kamera |
| Modell: | WV-S61301-Z2 |
Szüksége van segítségre?
Ha segítségre van szüksége I-PRO WV-S61301-Z2, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek
Útmutatók Térfigyelő kamera I-PRO
3 Január 2025
17 December 2024
17 December 2024
17 December 2024
17 December 2024
17 December 2024
17 December 2024
17 December 2024
17 December 2024
17 December 2024
Útmutatók Térfigyelő kamera
- Térfigyelő kamera Qolsys
- Térfigyelő kamera Chacon
- Térfigyelő kamera Atlona
- Térfigyelő kamera Vtech
- Térfigyelő kamera Maginon
- Térfigyelő kamera Vitek
- Térfigyelő kamera Adj
- Térfigyelő kamera EverFocus
- Térfigyelő kamera Toshiba
- Térfigyelő kamera Blink
- Térfigyelő kamera Jung
- Térfigyelő kamera American Dynamics
- Térfigyelő kamera BirdDog
- Térfigyelő kamera Friedland
- Térfigyelő kamera Mobotix
Legújabb útmutatók Térfigyelő kamera
6 Április 2025
5 Április 2025
5 Április 2025
15 Január 2025
14 Január 2025
13 Január 2025
13 Január 2025
13 Január 2025
13 Január 2025
13 Január 2025
