Oldal 1/9
4K 18G HDMI Fixer with L/R &
Optical Audio De-Embed,
4K to 1080p down-convert
KD-FIX418A-2
Operating Instructions
2 1
Key Features
›
HDMI Correction:
Resolves common HDMI integration obstacles related to Hot Plug
Detection, EDID handshaking, HDCP authentication, and bandwidth
›
Audio De-embedding:
HDMI input audio is de-embedded on an analog 3.5mm
stereo and digital optical connector.
›
4K to 1080p Down Convert:
When enabled, resolution conversion is applied to
individual outputs(s) based on EDID from the connected display.
›
Ultra HD/4K:
Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4
(signals up to 18Gbps bandwidth)
›
HDCP Licensing:
Fully licensed and compatible with HDCP 2.2
›
HDR10 and Dolby Vision:
More life-like images through a greater range of luminance
levels
›
Resolution Support:
Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA,
UXGA) up to 4096x2160p.
›
Deep Color Support:
Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
›
Full Buffer System
™
:
Manages TMDS re-clocking / signal re-generation, HDCP
authentication to source & display, Hot Plug management, and EDID control
handshake
›
EDID Management:
Internal library with 15 internal EDID handshakes including 4K
with HDR in addition to native EDID data copied from the output/display
›
Digital Audio Format Support:
DTS-HD Master Audio
™
, DTS:X
®
, Dolby
®
TrueHD,
Dolby Atmos
®
›
ARC Pass-thru:
From connected ARC supported display to connected ARC supported
HDMI source
›
CEC Pass-thru:
From connected display to selected HDMI source
Included Accessories
› Power Supply: 5V/1A (5W) DC power jack, screw-in type. Model SK01T-0500100Z
› Mounting: 2x L-bracket
Table of Contents
About KD-FIX418A-2 .........................................................2
Usage Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Quick Setup Guide ...........................................................4
Rack Mounting:..............................................................4
Connections, LEDs, Slide Switches, and Rotaries......................................5
Specifications ...............................................................10
Important Product Warnings & Safety Instructions: ....................................11
How to Contact Key Digital......................................................12
Warranty Information..........................................................13
Note: Please visit www.keydigital.com for the latest product documentation and software
downloads. Product features and specifications are subject to change without notice.
About KD-FIX418A-2
Key Digital
®
KD-FIX418A-2 is a 4K 18G HDMI connectivity repair and audio de-
embedding solution for HDMI extension coupling and signal correction in all AV systems
applications. Analog and digital audio de-embedding on 3.5mm analog stereo & optical
digital connectors enable integration of HDMI signals into distributed audio systems,
audio DSPs, amplifiers, or sound bars. EDID handshake management, forced hot plug
detection, and optional 4K to 1080p down-conversion tools help overcome common
HDMI integration problems for ease of installation. KD-FIX418A-2 supports a variety of
SD, HD, VESA and Ultra HD 4K video standards and has HDR header information included
in many of the built-in 4K EDID handshakes for an optimized viewing experience.
2 3
Usage Modes
4K/18
G
4K/18
G
4K/18
G
4K/18
G
4K/18
G
Short HDMI
KD-FIX418A-2
18
Gbps
Source Boost
Long HDMI
KD-FIX418A-2
18
Gbps
4K/18
G
Short HDMI
KD-FIX418A-2
4K
1080p
4K Source
Short HDMI
18
Gbps
4K Source
Long HDMI
KD-FIX418A-2
18
Gbps
Short HDMI
18
Gbps
4K AppleTV
4K to 1080p Down-Convert Mode
Audio DSP / Amplifier / Receiver / Multi-Zone System
4K AV System
Signal Correction
Long HDMI
Long HDMI
Long HDMI
18
Gbps
L/R / PCM
Audio De-Embed
4K to 1080p Conversion
1080p Projector
*Maximum one active/directional HDMI cable may be used for 18Gbps signals
