Kramer Electronics Ltd.
KDS-17EN-SW2 - Contents
2
Contents
Contents _____________________________________________________________________________ 2
Introduction __________________________________________________________________________ 3
Getting Started ______________________________________________________________________ 3
Overview ___________________________________________________________________________ 4
Typical Applications __________________________________________________________________ 5
Controlling your KDS-17 device ________________________________________________________ 5
Defining KDS-17EN-SW2 ______________________________________________________________ 6
Mounting the KDS-17 Devices _________________________________________________________ 8
Connecting the KDS-17 Devices ______________________________________________________ 10
Configuring the Network Switch _______________________________________________________ 11
Installing the Kramer recommended SFP transceiver _____________________________________ 12
Connecting the Audio/Input Output ____________________________________________________ 12
Connecting to a KDS-17 device with RS-232 ____________________________________________ 13
Operating and Controlling KDS-17 Devices ____________________________________________ 14
Using the LCD Display _______________________________________________________________ 14
Operating via Ethernet _______________________________________________________________ 16
Using the KDS-17EN-SW2 Embedded Web Pages ______________________________________ 19
Dashboard: Overview of Streaming ____________________________________________________ 20
AV Settings: Define Video and Audio Output ____________________________________________ 22
EDID: Setting Display Metadata _______________________________________________________ 25
Device Settings: General, Network, Time & Date_________________________________________ 26
Security: Passwords, HTTPS, 802.1X and AES256 ______________________________________ 31
Gateway: CEC, RS-232 and IR definitions ______________________________________________ 36
Diagnostics: Status, Connections and Logging __________________________________________ 39
About _____________________________________________________________________________ 41
Upgrading Firmware_________________________________________________________________ 42
Defining Dante or AES67 Audio as an Audio Source or Destination ______________________ 43
Defining Dante input to the KDS-17EN-SW2 encoder_____________________________________ 43
Using Audinate Dante Software _______________________________________________________ 43
Technical Specifications _____________________________________________________________ 46
Protocol 3000 _______________________________________________________________________ 48
Understanding Protocol 3000 _________________________________________________________ 48
Protocol 3000 Commands ____________________________________________________________ 49
Result and Error Codes ______________________________________________________________ 67
Kramer Electronics Ltd.
KDS-17EN-SW2 - Introduction
3
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of
unique, creative, and affordable solutions to the vast range of problems that confront the video,
audio, presentation, and broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better!.
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to https://www.kramerav.com/downloads/kds-17en-sw2 to check for up-to-date user
manuals, application programs, and to check if firmware upgrades are available (where
appropriate).
Achieving Best Performance
Use only good quality connection cables (we recommend Kramer high-performance, high
resolution cables) to avoid interference, deterioration in signal quality due to poor matching,
and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
Position your Kramer KDS-17EN-SW2 away from moisture, excessive sunlight and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating for
an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
If using a power cord, only use the Kramer approved power cord.
