KT--INWB 107 Quick Start

P/N:

2900-301152QS

Rev:

1

Scan for full manual

KT--INWB Quick Start Guide 107

This guide helps you install and use your KT-107-INWBfor the rst time.

Go to www.kramerav.com/downloads/KT--INWB107to download the latest user manual and check if

rmware upgrades are available.

Step 1: Check what’s in the b ox

KT--INWB107-Wall Box for KT-107 Touch Panel In

1 Quick start guide

4 M3x8 screws with washers

Step 2: Get to know your --INWB KT107

KT--INWB107 is used for installing a touch panel in a concrete wall.

Step 3: Install the --INWB KT107

For concrete or block wall surfaces:

Use the Kramer -Wall Box for KT-107-INWBIn

KT-107 Touch Panel for concrete installations.

1. Make sure that the prepared opening in the

concrete ts the dimensions of the in-wall

junction box.

2. Insert the into the opening. KT--INWB107

3. Carry out Touch Panel installation instructions

as described in Quick Start: KT-107-INWL

www.kramerav.com/downloads/KT--INWL 107

Make sure to place the ush KT-107-INWB

with the plaster surface.

Technical Specifications

Environmental

Conditions

Operating Temperature

0° to +40°C (32° to 104°F)

Storage Temperature

-40° to +70°C (-40° to 158°F)

Humidity

10% to 90%, RHL non-condensing

Regulatory

Compliance

Safety

CE

Environmental

RoHs, WEEE

Type

Steel

General

Net Dimensions (W, D, H)

2015cm x 6cm x .5cm (7.9" x 2.4" x 6.1")

Shipping Dimensions (W, D, H)

34.4cm x 6.8cm 21cm (.5" x 2.7" x 8.3 x 13")

Net Weight

0.6kg (1.3lbs) approx.

Shipping Weight

0.8kg (1.8lbs) approx.

Accessories

Included

4 M3x8 screws with spring washers 4 at washers
