Használati útmutató Lotronic JDL034LED

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Lotronic JDL034LED (6 oldal) a effekt gép kategóriában. Ezt az útmutatót 13 ember találta hasznosnak és 8 felhasználó értékelte átlagosan 5.0 csillagra

©Copyright Lotronic 2012 Lotronic SA – Av. Z. Gramme 11 – B – 1480 SAINTES

L

L

E

E

D

D

P

P

A

A

R

R

T

T

Y

Y

L

L

I

I

G

G

H

H

T

T

(

(

J

J

D

D

L

L

0

0

3

3

2

2

L

L

E

E

D

D

/

/

J

J

D

D

L

L

0

0

3

3

4

4

L

L

E

E

D

D

)

)

INSTRUCTIONS

ENGLISH

CAUTION

Please read this manual before use.

For indoor use only

Please keep this unit out of reach of little children or pets.

Disconnect this product from power immediately in case of malfunction.

Do not resume use until it’s repaired.

Please unplug the power cord if you want to stop use of this unit forlong time.

Instructionsof Use

1. Carefully put this product onto a clean, flat, and solid surface, such as a tabletop or

Connectthe individual spots’ plug-in connectionswith the corresponding sockets on the

control unitcabinet-top, and connect to power.

2. Set the ON/OFF switch to ON position. You can now select the “SPEED” or “MUSIC”

functions using the two adjustable controlson the front of the control module.

3. To activate device’schasingfunction, turn the “MUSIC” controltothe left (selecting the

first possible setting). You can now use the “SPEED” controlto adjust the flashingspeed.

4. The“Sound response”function is activated using the left control. The light spotsnow

reacts both to light sequence and sounds. You can adjust the microphone’s sensitivity.

Select the desired flashingspeed using the “SPEED” controland adjust the integrated

microphone’s sensitivitylevel using the “MUSIC” control. The light spotswill now flash

according to the intensity of the sound near the unit.

5. To change coloureffect, please pull out all the plugs in the row jacks and detach the

combination tube for a new combination.

6. Please usea damp, soft clothfor cleaning.

Specifications

Operating voltage:

-Poweradapter input: 220-230Vac 50Hz

-Poweradapter output: 14 Vdc 300mA

Consumption: 3.6W

Light bulbs: 47 LEDs per module (red, yellow, orange, greenor blue)

Electric products mustnot be put into household waste. Please bring them to a recycling

centre. Ask your local authorities or your dealer about the way to proceed.
